Product Details
Company Details

NAUGRALABS LABORATORY PRODUCT NAME: UNIVERSAL PENDULUM IMPACT TESTER FOR TESTING LAB
NaugraLabs Laboratory Product Code: NLE-Export-111004

Description and Specification for Lab Tenders

Universal Pendulum Impact Tester.

Release of pendulum by Hand operation Safety guards for protection Braking arrangement provided to arrest the swing of pendulum after specimen rupture. Capacity 30kgM / 300 Joules Charpy and Impact Tension Test Izod Test Pendulum drop angle 140° 85° Pendulum effective weight 20.59 kgs. 21.79 kgs Pendulum speed 5.3465 m/sec 3.857 m/sec Pendulum Impact Energy 30 kgM (300 J) 16.4 kgM (164 J) Min. graduation 0.2 kgM (2J) 0.2 kgM (2J) Distance of axis of hammer rotation and centre of test piece/point of test piece hit by hammer 825 mm 825mm Max. permissible loss by friction X windage, etc 0.5% of max. impact energy mechanical lab equipments manufacturers
