Universal Sheet Folding Bending Machine

Listing ID #2062540

Get Latest Price

Supply Type Manufacturer, Retailer, Distributor

Preferred Buyer From : All over the world

View More Details

Product Details

This Universal Sheet Folding Machine is extremely versatile machine suitable for many applications.
This heavy duty sturdy Sheet Folding machine is well fabricated from MS steel with hinge points in roller bearings for effortless folding. The eccentrics and other pins are made from alloy steel duly hardened. Our universal folding machine incorporates adjustable truss bars which ensures accurate and straight folding even for full length jobs.
The sides of the machine are well fabricated using M.S. Tee and I beam. Both sides are connected with three tie bars to maintain strength.
The upper beam Ram of the machine is reinforced properly and equipped with three adjustable truss bars. It can move upto 200 mm to fix various types of fingers to facilitate taking different types of bends. It moves in dovetail slides for accurate work.
Clamping of sheet is done by the lower beam Table, which moves on the I beam. The movement of this lower beam is operated by two independent eccentrics on each side, aided by two strong springs to reduce the clamping pressure. Lower beam is also equipped with two adjustable truss bars.
The folding beam Apron, is adjustable vertically for taking sharp as well as radius bends. Adjustments can be done by apron bolts. Angle selector gauge is also provided for repeated jobs. Two handles on beam and two counter weights for effortless bending are fitted at the side of the paddle of apron.
For more details contact us .

Additional Information

Payment Terms T/T
Packaging Details wooden case packing.
Delivery Time six to eight weeks
