Contact Supplier- | Pipe Size IN MM | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 |
---|---|---|---|---|---|---|---|---|---|
SCH 40 | Average Outer Diam.(Mm) | 26.67 | 33.4 | 42.16 | 48.26 | 60.32 | 73.02 | 88.9 | 114.3 |
Min. Wall Thickness(Mm) | 2.87 | 3.38 | 3.56 | 3.68 | 3.91 | 5.16 | 5.49 | 6.02 | |
Max.Work Pressure Rating(Kg/Cm2) At 23oC | 33.75 | 31.64 | 26.01 | 23.2 | 19.69 | 21.09 | 18.28 | 15.47 | |
Burst Pressure (Kg/Cm2) | 106.2 | 99.3 | 81.4 | 73.1 | 61.4 | 66.9 | 57.9 | 49 | |
SCH 80 | Average Outer Diam.(Mm) | 26.67 | 33.4 | 42.16 | 48.26 | 60.32 | 73.02 | 88.9 | 114.3 |
Min. Wall Thickness(Mm) | 3.91 | 4.55 | 4.85 | 5.08 | 5.54 | 7.01 | 7.62 | 8.56 | |
Max.Work Pressure Rating(Kg/Cm2) At 23oC | 48.51 | 44.29 | 36.56 | 33.04 | 28.12 | 29.53 | 26.01 | 22.5 | |
Burst Pressure (Kg/Cm2) | 151.7 | 139.3 | 114.5 | 104.1 | 88.9 | 93.8 | 82.7 | 71.7 |
