Contact SupplierWe are offering used agilent n9912a rf handheld analyzer.
Key features & specifications
cable and antenna analyzer (cat), vector network analyzer (vna)
2 mhz to 46 ghz
directivity > 42 db
cat: distance-to-fault, return loss, cable loss
vna: s11 mag and phase, s21 mag, time doman with gating
spectrum analyzer, interference analyzer
5 khz to 46 ghz
danl: -148 dbm, +18 dbm toi
spectrogram, waterfall display, record and playback
independent source, vector voltmeter (vvm), power sensor and channel power measurements
rf source: 2 mhz to 46 ghz, cw and tracking
vvm: 2 mhz to 46 ghz, compare phase and electrical length
average and peak power measurements with usb sensor
channel power measurements: 100 khz to 46 ghz, no sensor needed
fieldfox instrument attributes
new: remote control via ipad or iphone
standard 3-year warranty
battery life: 4-hours; weight: 2.8 kg or 6.2 lbs
operating temperature: -10 to +55 °c (14 to 131 °f)
price: usd 8,350.00
