UV Weathering Test Chamber

External size1350 X 600 x 1560 mm (W x D x H)
Distance between lamps70mm
Ultraviolet lightUV-A: 315-400nm OR UV-B: 280-315nm, 8pcs, 1300h lifetime, length: 120 cm, ATLAS or PHILIPS make .
Humidity range≥ 90%RH
Supply TypeManufacturer, Exporter, Supplier, Retailer, Trader
Preferred Buyer Location All over the world

Company Information

Ask for more detail from the seller

Report incorrect details

Distance between lamps70mm
Irradiance1.1W/cm2
Testing time0 to 999 Hours
Water sprayNozzles w/ motor pump
Inner size1170 x 500 x 500 mm (W x D x H)
Power220V 50Hz
ConstructionStainless steel 304
Test cycle settingIllumination, condensation and water spray test cycle is programmable
ModelSTXUVW115
Air circulationBlower assembly with duct
Controller7” color touch screen controller, Programmable temp, humidity, UV & time, In-built data recording w/ USB port .
Temperature rangeAmbient+10°C to 70°C
Distance from samples to lamp50 ±2mm (adjustable)
External size1350 X 600 x 1560 mm (W x D x H)
Temperature uniformity±1°C
Protection systemOverload short circuit protection, Over temperature protection, Water lack protection, Earth leakage protection, Auto shut off protection, UV light off when door open .
UV Lamp power40W / per lamp
Standard Specimen Size75×150mm or 75×290mm
Temperature fluctuation±0.5°C
Humidity range≥ 90%RH
Ultraviolet lightUV-A: 315-400nm OR UV-B: 280-315nm, 8pcs, 1300h lifetime, length: 120 cm, ATLAS or PHILIPS make .
