V Shaped Wire Welded Stainless Steel Screens (iso9001:2008 Factory)

V shaped wire welded stainless steel screens (iso9001:2008 factory)
1.material:steel wire,ss 304,ss 304l,ss 316,ss 316l
2.specification:
(1).profile wire size: 2.2mmx3.5mm, 2.2mm x 4.5mm,3.5mm x4.5mm,2.5mm x 4.5mm
(2).slot width:0.5mm-1.0mm
(3).support wire size: 2.2mm x 3.5mm,2.2mmx4.5mm,3.5mm x4.5mm,2.5mm x 4.5mm
(4).pipe screen diameter:2inch--20inch. (89mm,152mm,219mm,254mm)
(5).pipe length: can up to 12m.
3.features:
(1).filter pipe with high porosity is more efficient for the construction of water, oil and gas wells.
(2).filter pipe with low operating costs and high porosity is more conducive to groundwater infiltration, and plenty of deep water make the water level drop reduced, thereby reducing energy consumption.
(3).reducing pump wear, under the same conditions, the high porosity makes groundwater infiltration rate in the filter pipe penetration rate more slowly compared to other filtration apparatus, thus avoiding the sand enter the filter pipe in the larger pressure,reducing pump wear.
(4).to extend the life of the well, relatively speaking, a high groundwater infiltration drainage pipe filter pores easier, low flow rate, extending the life of the well.
4.application:
can be used with deep well,submersible pumps,and can also be used as water treatment equipment for environmental protection, desalination of seawater into the treatment of industrial water and domestic water, water treatment, water softening treatment, the petroleum industry: oil filtration and recycling end-product of chemical organic solution of acid, alkali liquid filtration, alcohol and other filtering. Can also be used for hydro-geological exploration, drilling, drilling, construction, reservoirs precipitation, foundation digging precipitation, geothermal development and utilization of mineral exploitation, geothermal air conditioning, repair broken wells,underground water sources
