Vacuum Brick Machine

We are offering jzk60-4.0 vacuum brick machine.
1.main purpose of serial briquette machine
applicable to ball making and re-smelting of fine materials of supplementary materials of non-ferrous metal and ferrous metal’ material fines in metallurgy industry, such as sludge, oxide scale, dust-ash, iron fine, raw material powder, manganese ore powder and silicon manganese.
applicable to ball making and agglomeration of coal dusts in chemical industry of building materials for replacing lump coal and saving cost and that of coal dusts for gas making in ceramic factory , glasswork and coal gas producer in building material industry for the replacement of lump coal and cost saving.
applicable to ball making and agglomeration of refractory material s in refractory industry and that of coal dust used for gas making of cal gas producer to replace the lump coal and save cost.
2.operation principle of serial briquette machine
this serial briquette machine uses main motor to transmit the motive powder to speed reducer through the v-shape triangle belt and to main drive spindle through coupling, and then uses the main driven split gear to send it to the main driven spindle to make the two rollers fall into step (inverted running with uniform speed )
3.structure and components of briquette machine
it mainly consists of a frame(or an underchassis), speed reducer, upper and lower frame, spindle seat, main spindle, main bearing, coupling, king roller, side roller, wheel hub, main driven gear, ball socket deviation adjuster, bearing seat, main assemblage of papilionaceous springs, oil cylinder, piston, oil pump, feeding funnel and output belt.
