Vertical Machining Center

Brand NameV 650
Number Of FlowerVertical
Country of Origin220V/240V/380V
Total Carbohydrate1 Year
Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

Product Details

Number Of FlowerVertical
Brand NameV 650
Country of Origin220V/240V/380V
Total Carbohydrate1 Year
CertificationCE ISO
After-sales Service ProvidedEngineers available to service machinery overseas
Conditionnew

Vertical Machining Center
CNC Milling Machine
VMC650
Table size (mm)
800*400
Table load max (kg)
300
XYZ travel (mm)
650*400*500
Spindle nose to table (mm)
100-600
Spindle center to column surface
360
Spindle taper
BT40
Spindle speed (r.p.m)
40-8000
Spindle motor-inverter (KW)
5.57.5
Table fast speed (mmin)
161620
Feeding speed (mm)
1-5000
Positioning Accuracy
+- 0.005mm
Repeatability
+- 0.005mm
ATC Change
Arm or Hat
Tool Capacity
162024
Guideways
3-axis*boxways
(Linear guides Optional)
N.W. (kg)
3500
Machine size (mm)
2650*2160*2500
Siemens 808D basic or China KND controller, Taiwan Spindle,
HiwinPMIChina brand linear guides Optional,
45-axis ( Rotary table of China mainland brands or Tiawan brands Optional)
Special specifications VMCs asper customers' parts required are avail.
Robot loadingunloading Optional.
