Vertical Molding Machine

Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

We are counted among the top Manufacturers and Suppliers of Vertical Molding Machine that is of great use in plastic, automotive, engineering and many other industries. It is also good for....

View More Details

Send Enquiry

Product Details

We are counted among the top Manufacturers and Suppliers of Vertical Molding Machine that is of great use in plastic, automotive, engineering and many other industries. It is also good for fabricating PET performs bottle caps, house-hold items and many other products. The best thing about our Vertical Molding Machine is that it adheres to advanced trends and international quality parameters. Also, it is made available at the best market price.

Mechanical Properties :

The castings of the whole machine are made of high quality Meehanite cast iron which is already annealed to eliminate stress.
Optimized lathe bed structure guarantees excellent dynamic stiffness of the machine tool.
The guide rails of three axes are fully enclosed with protective covers with outstanding protective properties.
Pneumatic broach device means simple and fast tool change.
Lubricating oil circulation device supplies oil to the ball screw on periodic basis or based on the stroke to prevent the screw from expanding in case of heat, and to extend the service life of the screw and bearing, and to ensure stable processing quality even after years of use.
The machine tool is equipped with original high-speed precision spindle from Taiwan, original high precision ball screw from Taiwan, NSK Bearings from Japan and Germany couplings to ensure precision and long service life of the machine tool.

Technical Specifications

Item/model		unit	YF6046	YF1056	YF1265A	YF1375A	YF850	YF1060
Moving stroke section	X-axis stoko	mm	600	1200	1200	1300	800	1000
	Y-axis stoko	mm	460	560	650	750	500	600
	Z-Axis sroko	mm	530	620	650(600)	600	530	620
	Distance between spindle nose and workbeech plane	mm	140~670	150~770	200~850 (200~800)	200~820	140~670	150~770
Workbench section	Size of workbench	mm	750×450	1100×525	1300×650	1300×650	800×500	1100*600
	T-slot(width×quantity×pitch)	mm	18×4×100	18×5×100	18×5×125	18×5×125	18×4×100	155100
	Maximum load of workbench	kg	350	800	1000	1600	350	800
Spindle section	Spindle motor power (continuous /30 minutes)	kw	5.5/7.5	7.5/9	9/11	11/15	7.5/11	11/15
	Spindle speed	Rpm	60~8000	60~6000	60~8000	60~6000 60~8000	60~8000	60~6000
	Spindle taper	No.	BT40	BT40/BT50	BT40/BT50	BT50	BT40	BT40/BT50
Feed section	Power of X-axis, Y-axis, Z-axis servo motor	kw	1.6	3	4	4	1.6	3
	Terque of X-axis, Y-axis, Z-axis servo motor	mm	8	12	22	22	8	12
	Three-axis rapid traverse rate X/Y/Z	m/min	18/18/15	18/18/15	20/20/20	20/20/20	36/36/18	32/32/18
	Cutting feed rate	m/min	1~5000	1~5000	1~5000	1~5000	1~5000	1~5000
Three axis precision	Positioning accuracy	mm	0.008/300	0.008/300	0.008/300	0.016	0.012	0.012
Three axis precision	Pepeeted positioning accuracy	mm	±0.004	±0.004	±0.004	0.008	0.006	0.006
Automatic tool change section	Automatic tool change
	Capacity of tool magazine	T	16	24	24 20	24	16X20	24
	Maxinum tool dancter×weight×length	M×kg×m	Φ90×8×300 Φ150	Φ90×8×300 Φ150	Φ50×8×380Φ112×15×380Φ×175Φ280	Φ112×15×300 Φ200	Φ90×8×300 Φ150	Φ90×8×300 Φ150
	Automatic tool change time	S	8(3)	8(3)	3	3	8(3)	8(3)
Others	Machine weight	Kg	4200	6000	10000	12000	5200	6500
	Total power of machine	KVA	15	20	25	25	15	20
	control system (optional)	FANUC SIEMENS MITSUBISHI HA-500
	size of package	Mm	2450×2260×2516	2700×2350×2742	3600×2700×2800	4200×2960×3145	2450×2260×2516	280023502742
