Following are the Features
A total cGMP ModelS.S.304constructionAccurate Label placement. PLC based system with touch screen HMI.“No Vial No Label” System Auto Length adjustment of labelNo Change part required for change over of each container sizeTool less guide adjustmentInkjet printer / Hot foil Printer / Rubber stereo printer (Optional)Camera Inspection System for checking Barcode /Pharma Code & OCR (Optional)Auto Rejection for Barcode / Pharmacode / OCR (OPTIONAL)Auto Label AdjustmentMachine on wheel for easy movingEasy adjustmentImported delrin belt for conveyor.Conveyor & servo speed synchronized and controlled from HMI.Minimum accumulation at Infeed machine stop with Auto Restart (Optional)Maximum accumulation at Outfeed machine stop with Auto Restart (Optional)Rejection Bin Full sensor (Optional)
| Model No. | ATL-120. | ATL-250. |
|---|---|---|
| Production Rate | Up to 120 Vials/Min. | Up to 240 Vials/Min. |
| Electrical Supply | 2.5 HP | 2.5 HP |
| Power Requirement | 415 Volts, 3 Phase (4 Wire System), 50 Hz. | 415 Volts, 3 Phase (4 Wire System), 50 Hz. |
| Height of Conveyor | Adjustable from 850 to 900 MM | Adjustable from 850 to 900 MM |
| Dimension | 2000 MM(L) x 1000 MM (W) x 1780 MM (H) | 2000 MM(L) x 1000 MM (W) x 1780 MM (H) |
| Net weight | 300 Kgs. (Approx). | 300 Kgs. (Approx). |
| Gross weight | 500 Kgs. (Approx). | 500 Kgs. (Approx). |
| Label Height | 10 mm to 160 mm | 10 mm to 160 mm |
| Label Length | 12 mm to unlimited | 12 mm to unlimited |
| Gap between Two Labels | Min. 5 mm | Min. 5 mm |
| Label Roll Dia. | 300 mm Max. | 300 mm Max. |
| Label Core Dia. | 75 mm to 76 mm | 75 mm to 76 mm |
| Container Dia. | 20 mm to 90 mm | 20 mm to 90 mm |
