Vertical Strapping Machine

We are offering vertical strapping machine,
machine dimensions(mm) l * w * h+weight: 3950 * 660 * 2883+550kg
standard arch dimensions(mm) w*h: 2250*1600(can be customized)
standard package dimensions(mm) w*h: (1000-1200)*(800-2000)
pppet strap dimensions: strap width:12,15,19mm
strap tension: max. 700n (adjustable)
strapping speed: 15sper strap
operate mode(with touch screen): manual +auto(easy to install to fully automatic packing system)
plc control system: the strapping head has 250mm shift motion(400mm optional)
auto-caution when strap is not feed to the right position: both available for pp and pet straps
suitable to install to fully automatic packaging production line: customized non-standard design
plc control system: the strapping head has 250mm shift motion(400mm optional)
auto-caution when strap is not feed to the right position.: both available for pp and pet straps
suitable to install to fully automatic packaging production line: customized non-standard design
auto alarm when abnormal condition emerge: equiped with pallet void feeder for pallet strapping.
open type flexible arch. all steel structure,sturdy supporting frame.
Using combine with ht-100,the safety of goods on pallet will be 100% guaranteed.
power: 380v. 5060hz. 3 phase. 1.2kw.
