Vertical Universal Friction Tester, Brand Name : Yihua

We are offering computer controlled vertical universal friction and wear tester.
application
this product can finish the friction simulation test between different friction pairs.it is used to evaluated friction properties of lubricant,metal,coating,rubber,ceramics etc.materials.
technical parameters
1.loading range of test force:10-1000n
2.relative error:less than 200n, ≤+-1n
more than 200n, ≤+-1%
3.relative error under maintaining: +-1%fn
4.friction torque:0-2500n*mm error:less than +-2%
5.length of friction arm:50mm
6.relative error back to zero: less than+-0.2%fn
7.spindle speed: 1-2000rmin
8.relative error：under 100rmin,≤+-1rmin,more than 100rmin,≤+-5rmin;
9.medium: air, petrol,water,mud,abrasive etc.
10.heating range: room temperature-260℃，relative error：+-2℃
11.ptc heating panel：60*40，220v，300w
12.timing setting range:1s-9999min
13.dimension:830*700*1500mm
14.weight:appro.300kg.
