Contact SupplierTechnical Specification | ||||
Two Head | Four Head | Six Head | Eight Head | |
Output/Hour | 3000/Hour | 6000/Hour | 9000/Hour | 12000/Hour |
Capacity | 2ml to 100ml –With the help of change parts | |||
Accuracy | ± 1 % Filling accuracy on single doze | |||
Electrical Rating - Main Machine Motor - Conveyor Motor |
1.00 H.P. (for Two/Four/Six Head Machine) 1.50 H.P. (for Head Head Machine) 0.5 H.P. |
|||
Power required | 230 Volts, Single Phase.50 Hz (4 wire system) | |||
Conveyor Height | 780mm to 860mm adjustable | |||
Input specifications | Dia.- 16mm x 55 mm Height- 110mm |
|||
Stopper | 13mm, or 20mm | |||
Filling Rnge. | 2 ml To 50ml in Single stroke. 100ml in Double Stroke. |
