Vibrating Feeder, Availability : 100-200kg

We are offering vibrating feeder.
Application fields: the product is usually applied to feed jaw crusher. It is widely used in the crushing and screening plant in the field of mineral processing, building materials, water conservancy, and chemical industry. For example, feeding and blending to the crushing, coal filtering, screening, transportation, packaging machines and so on.
Suitable material: the feeder of this series produced by our company is linear grizzly vibrating feeder, which applies a manner of vibration generator, having the features of stable vibration, reliable operation and long life expectancy.it can continuously and uniformly feed for the crusher so as to improve the mechanical performance and continuous working capacity.besides, this machine has a large screening capacity.
Technical date：
model max.feed
particle size
(mm) capacity
(th) eccentric
axle speed
(rmin) type of
motor motor
power
(kw) motor
speed
(rmin) motor
qty. installation
angle
oo mechanical
dimensions
(l×w×h) mechanical
weight
(t) chute sizes
(mm×mm)
zsw-360×90 220 200-280 800 y160m-4 11 1500 1 0 3768×1992×1997 3.69 3668×895
zsw-380×96 500 90-100 500-714 y180l-8 11 750 1 0 3882×2224×2121 3.98 3800×960
zsw-490×96 500 120-240 500-800 y180l-8 15 1000 1 0 4957×2277×2150 5.0 4900×960
zsw-600×100 600 350 800 y200l-4 30 1500 1 0 6102×1835×2215 7.25 6000×1000
zsw-490×110 580 120-280 500-800 y180l-6 15 1000 1 0 4957×2400×2150 5.32 4900×1100
zsw-590×110 600 350 750 y180l-4 22 1500 1 0 6000×2500×2150 6.13 5900×1100
zsw-480×120 600 280 800 y200l-4 30 1500 1 0 4900×2700×2120 6.4 4800×1200
zsw-600×130 750 400-560 500-800 y180l-4 22 1500 1 0 6082×2580×2083 7.8 6000×1300.
