Product Details
Company Details

Product Code: EKE 837 to EKE 839

Vibrating Wire Centre Hole Load Cell:

Same as EKE 831 to EKE 836, but with six parallel Vibrating Wire Gauges, located 60º apart in cylinder wall. Centre Hole Bearing Plates
Centre Hole Bearing Plates comprising epoxy painted steel discs with central hole for use with EKE 831 to EKE 839 load cells for monitoring tension in rockbolt or cable anchors. The plates incorporate three location dowels to assist concentric mounting of the load cell. Details of dimensions as tabulated :

Installation Accessories
EKE 83131 Connecting Cable
For use with EKE 831 to EKE 836 Vibrating Wire load Cells. Six Conductor Copper Wire, insulated colour coded and screened with sheathing
EKE 83731 Connecting Cable for use with EKE 837 to EKE 839 Vibrating Wire load Cells, twelve Conductors, copper wire insulated, colour coded and screened with sheathing
EKE 83125 Splicing Set To be used with EKE 83131connecting cable
EKE 83725 Splicing Set To be used with EKE 83731 connecting cable

Dimensions And Range

Catalogue No.	Working Load (kN)	*Overall Dia (mm)**	Centre Hole	Height (mm)
EKE 831	250	102	40	80
EKE 832	500	121	50	80
EKE 833	500	152	90	80
EKE 834	1000	146	50	80
EKE 835	1000	165	90	80
EKE 836	1500	220	150	80
EKE 837	2000	275	190	80
EKE 838	3000	292	190	80
EKE 838	4000	292	190	80

Centre Hole Bearing Plates: Dimensions

Catalogue No.	Working Load (kN)	*Overall Dia (mm)**	Centre Hole	Height (mm)
EKE 83101	EKE 831	103	40	23
EKE 83201	EKE 832	113	50	33
EKE 83301	EKE 833	143	90	33
EKE 83401	EKE 834	136	50	43
EKE 83501	EKE 835	163	90	43
EKE 83601	EKE 836	218	150	48
EKE 83701	EKE 837	262	190	58
EKE 83801	EKE 838	278	190	63
EKE 83901	EKE 839	292	190	68
