Video Projector

We offer video projector .
product features
1. The touch screen and measuring technologies are combined, make operation easier and function more practically.
2. Led light can be used more than 100,000 hours, it also overcomes the shortages of halogen light, which is short life and more heat and used on traditional projectors.
3. Z axis design in a lifting way ensure the worktable bear greater weight more than 20 kg and use for long time, which overcomes the shortages of bearing less weight and short life of traditional projectors.
4. The software can used in measuring gear, taper and thread.
applied fields
gear, mould, rubber industry, electron, hardware industry, metal work, mobile phone accessory, pcb, plate work pressing, terminal connector, household appliance, electronic parts, precision fixtures and so on.
technology parameters
model
sp-vcs-200
sp-vcs-250
sp-vcs-300
measuring range(x/y:mm)
200?00
250?50
300?00
dimension(mm)
650?00?600
operation mode
manual
magnification
20x-120x
screen
17" touch screen led monitor
software
ots
lens w.d (mm)
95
optical ruler resolution
1um
precision
(3+l/200)um
repeatability
5um
ccd
430,000 pixel color ccd
load capability
20kg
applicable environment
power:110v~220v?0% 50/60hz
temperature: 20? oc humidity: 45%-75%
free maintain time
one year.
