Wall, Roof Sheet Roll Forming Machine

We offer roll forming machine
1. The chart of process flowdecoiling--active feeding--roll forming--measuring length--cutting tolength--product to stand
2. Introduction of equipmentdecoiler, main forming machine, hydraulic cutting, product stand, hydraulicsystem, electric system.
3. Technical specifications
1) manual inner tight decoilera. Coil inner diameter: 450mm-700mmb. Maximum width of coiling: 1200mmc. Maximum weight of loading: 6000kg
2) main forming machinea. Number of forming steps: 12b. Material of shaft: 45# steel adjustable treatment.outer diameter: 70mm
c. Material of roller: high grade 45# steel(plated chrome on surface)d. Main motor power: 3.7kwe. Forming speed: 6-12m/minf. Stand: 350# steel weldingg. The plating chromium of roller surface: 0.05mm
3) hydraulic cuttera. Material of blade: cr12 mould steel with quenched treatment 60-62°cb. Cutting system: adopt advanced hydraulic drive, after forming automatic cut,no distort, no wasting , high safe factor.(main motor stop cutting)
4). The electrical control system
a. Screen display: 5.7 inch touch screen of taidab. The main computer (plc): tai da dvp14esc. Encoder: enc-1-1-1t-24 of north korea
5). Hydraulic systema. Adopting advanced hydraulic system of tai wanb. Power: 4kw
4. The whole machine consists of: manual inner tight decoiler: 1 set; mainforming machine: 1 set; hydraulic system: 1 set; electrical system: 1 set,normal product stand: 3 set
