Warm White LED Panel Light, Brand Name : TLSANLI

We are offering Round Dia240mm LED Panel Light Warm White 18W with Dali Dimmable & Emergency.

Model No: iPanel -240ww-18W
Parameters for iPanel LED Panel Light.

1. Power: 18 watt
2. Input voltage: AC 100-240V
3. Color temperature: cool white, natural white, warm white
4. CRI: high Ra >82CRI and 90 CRI ensures greater color definition
5. Power factor : >0.95
6. LED chip: super quality SMD2835 approved IESNA LM-80-08 (USA Energy Star)
7. Body material: Die-casting Aluminum + shinning or frosted diffuser + super 4mm light guide plate make sure high light uniformity+ 1mm back plate.
8. Dimension: Dia240xH12mm, cut-out size 216mm
9. Color: warm white, natural white, cool white
10. CCT: 2700-6300 Kelvin or custom color temperatures available
11. Luminous: 1685 lm (real lumen output after diffuser, not initial)
12. Beam angle: 120 degrees
13. External constant current driver: Mean Well, tridonic, inventronics etc.
14. Dimmer: DALI, TRIAC, WIFI, 0-10V, 1-10V, PWM for option.
15. Emergency: self-testing emergency or regular 3hours emergency packs, Nicd battery.
16. Lifespan :> 50, 000 hours
17. Certificates: CE, RoHS, CUL, TUV (meets all safety regulations)
18. Warranty: 3 Years.
19. Work temperature: -20 Centigrade to 40 Centigrade
20. Frame color: matt white /aluminum grey or custom colors available.
21. Installation: recessed, surface mounting, suspension, all accessories such as hanging kits, clips, brackets etc are available.
22. Custom sizes and color temperatures available.
23. Weight: 1.5 kg
24. Packing: standard export carton, 6pcs per carton, carton size 440*380*300mm, total 10.7 kgs, and custom packing available.
25. Male and female connector.

Features of iPanel ultra slim LED Panel Light
#1: Suitable for recessed ceilings.
#2: Designed to replace Halogen, CFLs, fluorescent and incandescent lights.
#3: Save up to 50% in energy compared to a fluorescent module.
#4: Long life over 50,000hours, 10 times longer than fluorescent lamp
#5: Edge-lit panel technology, non-glare & high uniformity, no flicker.
#6: Well-being: no UV wave, RFI free, no dazzling, no tiredness for eyes, soft, evenly dispersed light.
#7 Dimming & Emergency options available.
#8: Eco-friendly: no mercury, longer life, no environment pollution, environment-friendly.
#9: LEDs Work separately: special circuit design, each group of LEDs work separately, avoiding any problem of lighting output caused or influenced by single faulty LED.
#10: Ultra-thin and neat design: ultra slim design, only 12mm. Modernistic looks.
#11: Revolutionary heat dissipation: integrated heatsink for effective heat dissipation and longevity.
#12: Extra insulation design, withstand flash voltage of 3750V

Applications of iPanel ultra slim LED Panel Light: suitable for modular and recessed ceilings, fits directly into ceiling grids or suspended/mounted.
1. Hotel, shopping mall, office lighting
2. School, colleges, university lighting.
3. Conference, meeting room lighting
4. Residential, institution building lighting
5. Factory, hospital lighting
6. Commercial complexes lighting
7. Retail lighting.
