Waste Tyre Pyrolysis Equipment, Brand Name : DOING

We are offering waste tyre pyrolysis equipment with high oil output.
a"wealth"
it's a new hot highly profitable green project, which can convert waste tiresrubberplastic to treasure (45% fuel oil, 35% carbon black and 15% wire steel)
1. Why more and more people are willing to invest this new project?
as we all know, rubbish (such as wate tire, waste plastic, waste rubber, waste oil etc.) are increasing every day. ------ how to dispose of these waste?
at the same time, oil resources are decreasing every day.------- how to deal with the problem?
we use green technology (pyrolysis and distillation) recycling waste to oil resourses. You may know that most of the fuel is the waste gas form the process, so it can save you cost and the waste gas return to burning as fuel, it is in accordance with the " turn the waste into wealth". Morever, the waste gas do not flow into the air, and protect the environment from polluting
it isabsolutely environmental friendly and creat great profits for you. this is a very high profit new project. We have successfully installed more than 60 sets machine in different country,india, iran, pakistan, poland, macedonia, turkey, albania ,malaysia etc.! any interests please feel free to contact us!
2. What the financial results from tyre pyrolysis recycling plant?
take one batch 10t waste tyre pyrolysis plant for example:
total output:
1. Crude oil: 45%*10t=4.5t
2. Carbon black: 35%*10t=3.5t
3. Steel wire: 13%*10t=1.3t
no. item cost of per batch
1 10 tons of waste tires 10t×usd 236t=usd2360
2 0.4 tons of coal 0.4t×usd126 t=usd50.4
3 water and electricity 200×usd0.16=usd32
4 workers salary 4×usd16=usd64
5 total cost usd2506.4
no. item income
1 crude oil 10t×45%×usd709=usd3190.5
2 carbon black 10t×35%×usd82=usd287
3 steel wire 10t×13%×usd34=usd450
4 gross profit usd3927.5
5 daily net profit usd3927.5-usd2506.4=usd1421.1
6 monthly net profit usd1421.1×25=usd35527.5
7 yearly net profit usd35527.5×10=usd 355275
note: it means that you can take back your investment and start to make profit within two months
3. Working processof waste tyre pyrolysis to fuel oil equipment :
1) feed the raw material into furnace automatically or manually, then seal the feed inlet system
2) heat the reactor by burning the fuel material(coal,or wood,or natural gas ,oil ) in the combustion system
the reactor will slowly become heat ,when the temperature reach around 250 degree celsius, the oil gas will be formed
3) after processed by our technology, the oil gas will go to cooling system for cold liquid oil
the gas which can not become liquid under normal pressure , will be desinged to go back to combustion system through safety device instead of the fuel material to burn the reactor, which is environmental friendly and can save you much energy
4)after finished oil produce ,the temperation of reacor will be down,while,carbon black can be discharged automatically
technical parameter of doing pyrolysis equipment
items contents
1 equipment type dy-1-6 dy-1-8 dy-1-10
2 raw material tiresplastic tiresplastic tiresplastic
3 structural form horizontal rotation horizontal rotation horizontal rotation
4 24-hour capacity 6 ton 8 ton 10 ton
5 oil yield 2.7ton 3.6 ton 4.5 ton
6 operating pressure normal normal normal
7 material of
reactor q245r q245r q245r
8 thickness of
reactor 14mm 14mm 16mm
9 rotate speed of
reactor 0.4turnminute 0.4turnminute 0.4turnminute
10 total power 19.5kw 19.5kw 19.5kw
11 mode of cooling water cooling water cooling water cooling
12 cooling area of
condenser 40sqm 40sqm 65sqm
13 kind of transmission internal gear drive internal gear drive internal gear drive
14 noise db(a) ≤85 ≤85 ≤85
15 size of reactor(d×l) 2200×6000 2200×6600 2600×6600
16 working form intermittent operation intermittent operation intermittent operation
17 delivery time 20days 20days 20days
18 weight 25t 30t 35t
