Water Cooled Screw Chiller, Cooling Capacity : 216kw

1.the plate-fin typed air-cooled condenser applies double-curved corrugated aluminum foil. Which is water-contactable. It is manufactured by specialized heat exchanger processing machine. Thanks for being extremely compact and light weight. As well as the high heat exchange efficiency and the ventilator with large rachis in slow revolution, the working noise level is obviously reduced so that the equipment is more environmental-friendly.
2.imported programmable logic control panel(plc)is used for the unit control system. The human machine interface configures a large touch screen. Which enables easy and visual operation.
3.the unit control system adopts a reliable safety protection equipment. E. G. Highlow voltage protector. Ventilation overheat protector. Compressor electrically protector over-current protector. Water flow protector. Emergency switch. Thermal sensitive soluble chock. Safety valve. Etc.
Item specification supplier
cooling capacity model ro-150a
kwh 364.4
power input kw 139
current a 223
temp outlet (℃) 6
power supply 415v-3n-50hz
refrigerant control expansion valve
refrigeration circle one
refrigerant r407c
dimension（mm）l×w×h 5800*2200*2300
compressor style semi-hermetic screw type
quantity（set） 1
compressor power(kw) 125.4
start way 0-25%-50%-75%-100%
condenser
style fin
air volume（m3h） 180000
fan power(kw) 13.6
evaporator style shell and tube 1set
cold water flow（m3h） 82.5
pipe size（dn） 125
protector device 1、phase protector
2、fan overload protector
3、highlow voltage protector
4、overheat protector
5、anti-freeze protector
unit weight（kg） 3800
operating weight（kg） 4800
main parts
compressor hanbell
electronic lg carlo
electromagnetically valve emerson
expansion valve emerson
electrical control punp
