Housing material: PBTPP wetted part
Mechanical installation: 2”GAS M on request PP flange DN80
Protection degree: IP65
Electrical connection: Internal push actuators connectors
Working temperature: 30 ÷ +70°C; +80°C non-continuous
Pressure: From 0,5 to 1,5 bar (absolute)
Power supply: 2-wire: 20÷30 Vdc 4-wire: 24Vdc
Power consumption: 2-wire max 0,6W 4-wire max 1,5W
Relays output: (4-wire only) -n°2 3A 230Vac
Digital communication: 4-wire: RS485 HART (optional)
Max measure range : Standard max 0.25÷5m (In case of non perfectly reflecting surfaces, the maximum distance value will be reduced)
Blind distance: 0.25m
Temperature compensation: Digital from -30 to 80°C
Accuracy: ±0,15 % (of the measured distance) not better than ±3mm
Resolution: 1mm
