Wax Injection Machine

Wax injection machine
c frame pillar type double stations
the wax injection machine is used to make wax patterns in the investment casting process with middle- temperature wax technology. It features with a multiple improvements of saving energy, high efficiency and good adaptability.
features
� advanced technology
it features with a bigger wax tank and introduces the technology of wax liquid cooling step by step to the paste condition suitable for the optimum process temperature in the wax tank.
Â�¢ reliable control
with a plc control system, the injection temperature, injection time and dwell time can be controlled automatically.
Â�¢ high-grade configuration
electrical components are allimported products or supplied by joint venture.
Â�¢ patent
injection nozzle and wax pipe are electrical heating, simple and reliable.
Â�¢ saving space
the two stations can work simultaneously, and suitable for the small and medium size product.
Â�¢ attractive appearance
besides the quality, we also pay special attention to the appearance design and surface treatment for our machines with the characters of reasonable process, advanced technology, beautiful appearance and fluent colors.
Specifications
model yt-smzj8t yt-smzj10t yt-smzj12t
structure c frame 2 pillars c frame 4 pillars c frame 4 pillars
clamp force max. 8t 10t 12t
injection pressure 0-6.3mpa 0-6.3mpa 0-6.3mpa
wax tank capacity 80-120l 80-120l 120l
single shot capacity �1.5l �1.5l �2l
note: we can design the special machines according to the customer�s requirements.
