50 Hz Semi Automatic Wax Injector, Power Source : Electric

Double station wax injector this machine is used to make wax sprue in investment casting process with the middle temperature wax. It is pneumatic driven, simple and reliable. It is equipped with a safety system to prevent misoperation. The time of wax injection, clamp open, clamp close can be adjustable. Specification model yt-smtj yt-smtj (a) clamp force 0-1.2t 0-1.2t injection pressure 0-0.6mpa 0-0.6mpa wax tank capacity 120l 120l clamping type one side with vertical clamping， the other side is horizontal clamping the two stations are all vertical clamping note: we can design the special machines according to the customer’s requirements.
