| Accuracy class | 0.5(0.2,0.3,0.4 customize) |
| Long-term stability | ± 0.2% F.S / Y |
| Repeatability | ± 0.2% |
| Medium | All kinds of liquid, gas and steam |
| Min flow rate | 0.01m/s |
| Measuring range | Normal: 1:25, max:1:33 |
| Pressure loss | About 1/5 of measuring differential pressure (1/3 orifice plate) |
| Reynolds number scope | Upper limit 500~1x107 |
| Medium viscosity | 500mpa.s or more |
| Working pressure scope | -0.1~42MPa |
| Working temperature scope | -160o C ~ 450 o C (max 700o C) |
| Pipe size | DN10mm~DN1200mm(max 2500mm) |
| Wedge ratio h/d | 0.2, 0.3,0.4,0.5 |
| Differential pressure transmitter powersupply | 24VDC |
