Road Buck Wheel Aligner, Rated Power : 50HZ/60HZ

We offer S980 four wheel alignment machine with ce.
Outstanding functions
� During operating, the cameras track the position of the vehicle and adjust to the corresponding height automatically.
� 3D Measurement: The 3D measurement technics which is based on real running surface of wheels, is more specific and precise.
� Shooting System: Composed of high-performance cameras and four targets disks, the camera system can measure the vehicle's running posture vividly.
� Target Disk: The solid-state target disks made of special materials and sturdy and durable without eletronic components.
� Pushing Measurement: None of any wheel compensation is needed. Only one pushing can complete the measurement.
� 3D Max System: The unique visual 3D max dynamic measurement system is real and vivid.
� Calibration System: Only one calibration is needed after the initial installation without any repetitive calibration following.
Other Features
�3D max Dynamic Display System
�No Electronic Components
�Four-point Wheel Clamps
�3D Animation Technics
�Reminding Window
�Pre-Tightening Rotatable Jaw
�Pushing the Vehicle Once
�3D Animation Adjustment Guidance
�Animation Operation Reminding
�Original Standard Database
�Caster and Kingpin Inclination Measurement
�Body Dimension Measurement
�Toe-out-on Turn Measurement
�Tire Diameter Measurement
�Maximum Turning Angle Measurement
Technical parameters
Item Accuracy Measurement Range
Display Precision 1�
Camber ±2' ±15°
Caster ±2' ±26°
Kingpin Inclination ±2' ±26°
Toe ±2' ±20°
Setback ±2' ±5°
Thrust Angle ±2' ±5°
