Wheel Alignment Machine With Android Function, Brand Name : GOLD JOHN

Advanced functions
★ control lifting pole;
★ Unique clamps’ calibration function;
★ Multiple interface display;
★ Gold John series with Android platform to display software(optional);
★ No periodic calibration
★ Accuracy can be reach to 0.1mm0.01°
★ More special features: camber adjustmentsteering wheel repair functiontyre radius measurement.
Gold John series outstanding features
1. With 3D proprietary intellectual property rights, we possess independent software source code;
2. Using the Japanese high quality lens, which is able to adapt to harsh light environment of the outside world and filter the noise of light, can effective recognize the targets and bring you a visual impact.
3.Target disks are made of special materials which will not be broken even falling from 10 meters high. And they are harsh temperature resistant.The reflection materials on the surface applys American superior engineering film, which can last longer working life.
4.The camera beam adapts aluminum alloy material, which is more rational and beautiful.
Service Strengths
1. Free data update, the update is 4 times per year, and the users enjoy unlimited free update;
2. With professional service technician, you can be rest assured of good after sales service. Our service network covers the whole country with excellent service team.
Technical parameters
Item Accuracy Measurement Range
Display Precision 1’
Camber ±2' ±15°
Caster ±2' ±26°
Kingpin Inclination ±2' ±26°
Toe ±2' ±20°
Setback ±2' ±5°
Thrust Angle ±2' ±5°
