Wireless Pan Tilt IP Camera

Description
1) The WIFI wireless IP network camera is video compressed by MJPEG. There are VGA/QVGA/QQVGA three video resolutions optional. User can change some parameters according to their demands to satisfy his own visual prefer.
2) With built-in Microphone, and also providing a interface for external microphone,it enables user to monitor the sound on the site. User can also connect this equipment to the speaker, and it supports two-way intercom function.
3) It was equipped with pan/tilt function, horizontally 350°and vertically 100°. Its outlook is smart, easy and convenient to install in many sites.
4) It adopts the TCP/IP network protocols and has inner web server. Users can browse video through IE and other browsers. Data is transferred through one port; it is easy for user to do the network setting.
5) Support 802.11b/g/n protocol, can build up wireless monitoring
6) Supports UPNP, port forwarding automatically on the router
7) Motion detection and alarm pin can be connected to external sensors to detect environmental situation
8) Alarming record can be stored by email, FTP server. External alarm can be open when detecting unusuality. It also sends alarm info to the alarm server
9) Infrared LED for night vision covers 5m area, to realize 24 hours monitoring
10) Support IR and color filter change automatically, no any color difference
11) Support mobile phone to view
12) Support three level of user authority
13) Support upgrading online
14) Manufacture attached a label at the bottom of each IP Camera, it include Device ID, DDNS. When IP Camera is connected to the internet, this URL can be used to visit the device
15) Manufacture provides free software, support Multi-view, Long time recording, video replay etc
Item Sub Item Description
Image Capture Sensor CMOS sensor
Total of pixel 300k
Minimum illumination IR on,0 Lux
Lens f=3.6mm, F=2.0, Fixed Iris
IR_CUT Support IR and color filter change automatically
Pan/Tilt Pan Coverage 350°
Tilt Coverage 100°
Assistant Lighting 8pcs 850nm Infrared LEDs, 5m distance
Lighting Control Auto control
Video and Audio Resolution 640*480(VGA)/320*240(QVGA)/160*120(QQVGA)
Compression MJPEG
Frame rate 30fps
Bit rate 128kbps ~ 5Mbps
Image Rotation Mirror /Flip
Audio Compression ADPCM
Network Basic Protocol TCP/IP,UDP/IP,HTTP,SMTP,FTP,DHCP,DDNS,UPNP,NTP,PPPOE
Other Protocol 802.11b/g/n
Other Features Video control support
Dual way audio support
Motion Detection support
Triggered Actions Email/FTP/external alarm/send message to alarm server
User Setting Three levels
Date/ Time Setting support
Upgrade Upgrade from network
DDNS A free DDNS provided by manufacturer
Hardware Interface Ethernet 10Base-T/100base-TX
Alarm In 1 way
Alarm Out 1 way
Audio In Internal Mic and External Mic interface
Audio Out Audio Line-out interface x 1
Physical Index Weight 343g
Main body 111mm(L)*107mm(W)*148mm(H)
Power DC 5V
Power consumption
