Wood CNC Router

₹ 4.48 Lakh / 7000 7000 Set

MOQ1 Set(s)
Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

We are offering wood cnc router . Specification gy-m1325a working area (x axis) 1300mm working area (y axis) 2500mm clearance (z axis) 200mm (300mm optional) spindle 3.5kw air-cooled spindle....

Company Information

Jinan Glory Import and Export Trading Co.,Ltd

Member Since 11 Years
Nature of Business Supplier
Year of Establishment 1998

Ask for more detail from the seller

Report incorrect details

Product Details
Company Details

We are offering wood cnc router .
Specification gy-m1325a
working area
(x axis) 1300mm
working area
(y axis) 2500mm
clearance (z axis) 200mm (300mm optional)
spindle 3.5kw air-cooled
spindle speed adjustable 0-18,000 rpm
tool change manual tool-change
drive system
(x & y axes) helical rack & pinion
drive system
(z axis) taiwan ball screw, 20mm
drive motors 4 sets stepper motors
inverter 3.7kw fuling
driver yako
command g code
cutter diameter φ3.175-φ12.7mm
maximum travel speed 35mmin
table top gridvacuum table tops with absorption function
vacuum pump 5.5kw water cooled
controller dsp handle
power requirements 3-phase 380v50hz, 220v optional.

Additional Information

Payment Terms L/C, T/TWestern Union
Port of DispatchQingdao
Packaging DetailsMachine is totally wrapped with stretch plastic, then packed into fumigation free wooden case
Delivery Time20 working days
