X-RAY SHIELDING GLASS

Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

LX-57B X-Ray shielding lead glass offers excellent radiation protection and superb visual clarity. The polished surfaces are scratch resistant and LX-57B does not discolor due to radiation. LX-57B....

View More Details

Send Enquiry

Company Information

Technical Glass Products

Dubai

View Number

Member Since 7 Years
Nature of Business Supplier

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

KEY FEATURES

High quality optical grade lead barium type X-Ray lead glass
Contains over 60% heavy metal oxide, including at least 55% PbO
Surfaces are mirror polished
Excellent for use in medical facilities, laboratories, airports, and screens for radiation
Available in 3 thicknesses, LX7 (7 mm) is used in most X-Ray radiation applications, LX9 (9 mm) and LX15 (15 mm) are used in cancer fluoroscopic treatment, etc.

LX7 may be installed in a double assembly for greater protection. Please call for further details.
Note: For applications requiring safety-impact resistant glazing, LX-57B is available with a surface applied film and in a laminated configuration.

Surface Hardness

LX-57B glass surfaces are mirror polished. Using Moh's hardness scale, LX-57B tests at Level 6 (comparable to feldspar, a constituent of granite). Acrylic tests at Level 3 (equivalent to calcite, a constituent of limestone and chalk).

AVAILABILITY

Please check with TGP for availability and lead time.

	LX7	LX9	LX15
Thickness	7 mm (1/4")	9 mm (3/8")	15 mm (9/16")
Lead Equiv. (mm)	1.6	2.0	3.0
Minimum Density gm/cm	4.36	4.36	4.36
Weight -- lb/ft2	6.55	8.19	13.11
X-Ray Peak Voltage KV	150	150	200
Max. available size	48" x 96"	48" x 96"	48" x 96"
