Yk Series Vibrating Screen

We are yk series vibrating screen.
Yk series inclined vibrating screens structure:
yk series inclined vibrating screens is composed by sieving box, mesh, vibration exciter and damper spring ect.
The vibratory screen adopts the vibration exciter with barrel type of eccentric shaft and block to adjust the swing. The vibration exciter is installed on the lateral plate of the sieving box.
The motor makes the exciter swing round speedily through tire coupling. The continuous forced circular motions of sieve box were achieved through the powerful centrifugal force. The lateral plate made by the high quality steel plate without any welding point. The lateral plate, beam and the vibration exciter connected by the high strength bolts and ring-grooved lockbolts.
Technical date:
model screen deck installation slope deck size（m2） vibration frequency（rmin） double amplitude（mm） capacity（m3h） motor power（kw） overall dimensions（l×w×h）（mm） weight（kg）
2yk1224 2 15 2.88 970 6-8 20-120 5.5 2673×2382×2027 1750
yk1235 1 15 4.2 970 6-8 20-150 5.5 3710×2464×1450 1729
2yk1235 2 15 4.2 970 6-8 20-150 7.5 3705×2393×2339 2476
3yk1235 3 15 4.2 970 6-8 20-150 7.5 3621×2521×2581 3158
4yk1235 4 15 4.2 970 6-8 20-150 11 3510×2521×2830 4160
yk1545 1 17.5 6.75 970 6-8 22-150 11 4904×3044×2179 3319
2yk1545 2 17.5 6.75 970 6-8 22-150 15 5042×3090×3165 5308
3yk1545 3 17.5 6.75 970 6-8 22-150 15 4972×3090×3395 5915
4yk1545 4 17.5 6.75 970 6-8 22-150 18.5 4915×3155×3804 7260
yk1548 1 17.5 7.2 970 6-8 22-150 11 5190×3044×2186 3319.
