Zinc Alloy Gravity Die Casting Machine

We are offering zinc alloy gravity die casting machine,
over 20 years factory,own the domestic first-class team and professional design team,integrating production ,sales and after-sales ,own exporting license,high quility products,competitive price,oem,timely delivery.
zinc alloy gravity die casting machine jd-950
i. Introduction
1. Application
zinc alloy gravity die casting machine jd-950 is a machine which is used in casting not only aluminum but also zinc and some other metals. For brass and copper casting, please refer to our products gravity die casting machine jd-ab500 and jd-ab400.
2. Machine components
the machine consists of three parts, such as mechanical part, hydraulic part and electrical part. Material used in mechanical part is well-selected steel. Both pneumatic and electrical part use products of world-famous brands. Therefore we can assure you that our products are of high quality.
3. Main specifications and technical parameters:
1) the mould specification: 900*650mm
2) minimum stroke of mould clamping: 400mm
3) maximum stroke of mould clamping: 900mm
4) turing angle: 0-90 deg
5) stroke of top mould: 100mm
6) stroke of core- pulling: 100 (designed as requied)
7) output volume of plunger pump: 37.8cc/ rev
8) system pressure: 0-10 pa
9) motor power: 3.75kw
10) vertical stroke: 500(125x500)mm
11)flipping stroke of oil sylinder (80* 360): 360mm
12) top oil cylinder stroke 100x100: 100mm
13) top oil cylinder stroke 80x100: 100mm (the stroke of the oil cyliinder is adjustable )
note:
for zinc alloy gravity die casting machine we have several models, like jd-550, jd-600, jd-700, jd-800, jd-950, etc. It's specification varies as different customers' requiements.
