Our offered Product range includes Schottky Rectifier, Coating Thickness Gauge, Metal Detector, Cable Fault Locator and Ultrasonic Thickness Gauge.
| Model | HSA2016A | HSA2016B | |
| Frequency Range | 9KHz~1.6GHz AC Coupled | 9KHz~1.6GHz AC Coupled 5M~1.6GHz TG | |
| Frequency Resolution | 1Hz | ||
| Reference Frequency | 10MHz | ||
| Frequency Readout Accuracy | ±(frequency indication*frequency reference uncertainty+1%*span+20%RBW+marker resolution+1Hz) | ||
| Internal 10MHz Reference Accuracy | Aging rate | ±1ppm/year（0℃~50℃，Reference is 25℃） | |
| Temperature stability | ±1ppm/year | ||
| Marker Resolution | (Frequency span)/(number of sweep points-1) | ||
| -3dB Bandwidth | 10Hz to 1MHz，1-3-10 sequence | ||
| Accuracy | ±5% RBW=10Hz~1MHz nominal | ||
| Resolution Filter Shape Factor | ＜5:1 nominal | ||
| Video Bandwidth (VBW） | -3dB bandwidth | 1Hz to 1MHz，1-3-10 sequence | |
| Accuracy | ±10% VBM=1Hz~1MHz nominal | ||
| Displayed Average Noise Level (normalized to1Hz) | |||
| 9K~1MHz | Preamp off | -108dBm，typical -127dBm | |
| 1MHz ~10MHz | -128dBm，typical -146dBm | ||
| 10MHz ~500MHz | -142dBm，typical -146dBm | ||
| 500MHz ~2.5GHz | -141dBm，typical -145dBm | ||
| 2.5GHz ~3GHz | -140dBm，typical -144dBm | ||
| 9K~1MHz | Preamp on | -131dBm，typical -150dBm | |
| 1MHz ~10MHz | -148dBm，typical -163dBm | ||
| 10MHz ~500MHz | -161dBm，typical -164dBm | ||
| 500MHz ~2.5GHz | -159dBm，typical -162dBm | ||
| 2.5GHz ~3GHz | -158dBm，typical -161dBm | ||
| SSB Phase Noise | Carrier Offset(20℃~30℃，500MHz Central Frequency） | 10K | < -92 dBc/Hz, typical -95 dBc/Hz |
| 30K | < -93 dBc/Hz, typical -96 dBc/Hz | ||
| 100K | < -95 dBc/Hz, typical -97 dBc/Hz | ||
| 1MHz | < -117 dBc/Hz, typical -119 dBc/Hz | ||
| Range | Span >100Hz | 2ms to 1000s | |
| Span=0Hz | 600ns to 200s | ||
| Sweep Mode | Continuous, single | ||
| Trigger Source | Free run; video; external | ||
| Trigger slope | Selectable positive or negative edge | ||
| Trigger delay | Span =0Hz | ±12ms to ±12s nominal | |
| Frequency Counter | Counter Resolution | 1Hz | |
| Accuracy | ± (marker frequency × frequency reference uncertainty + counter resolution) | ||
| Log Scale and Units | 1 to 10 dB/divisions in 1, 2, 5, 10 dB steps, 10 divisions displayed | ||
| Linear Scale and Units | 0 to 100%，10 divisions displayed | ||
| Scale Unit | dBm，dBmV,dBuV,Watts，Volts | ||
| Sweep (Trace) Points | 461 | ||
| Number of Markers | 4 | ||
| Detectors | Normal, positive peak, dample, negative peak, RMS | ||
| Number of Traces | 4 | ||
| Trace Functions | Clear/write, maximum hold, minimum hold, average, check，close | ||
| Level Measurement Error | ±1.5dB(excluding input VSWR mismatch) 20~30℃，peak detector, preamplifier off, input signal -50dBm to 0dBm | ||
| Setting Range | -100dBm to +30dBm, steps of 1dB | ||
| Setting Resolution | Log scale: 0.01dB | Linear scale: Almost log(2.236μV to 7.07V） | |
| Maximum Safety Input Level | Average continuous power: +33dBm | DC input voltage: 50Vdc | |
| Measurement Range | 9KHz~2MHz | Displayed average noise level (DANL) to +10dB | |
| 2MHz~3GHz | Displayed average noise level (DANL) to +20dB | ||
| Input attenuator range | 0 to 51dB,1dB steps | ||
| Second Harmonic Distortion（SHI） | <65dBc，50MHz to 3GHz（Mixer level -30dBm，attenuator =0dB，preamp off，20℃~30℃） | ||
| Second Harmonic Distortion（SHI） | <65dBc，50MHz to 3GHz（Mixer level -30dBm，attenuator =0dB，preamp off，20℃~30℃） | |
| Third-OrderIntermodulation(TOI） | 50~300MHz | +8dBm，Third-order intermodulation products：2 x -20dBm; frequency separation 100KHz：attenuation = 0dB; preamp off，20℃~30℃ |
| 300MHz~1.6GHz | +10dBm | |
| Input Related Spurious | <-75dBc，(input mixer = -30dBm) | |
| Inherent Residual Response | <-90dBm，typical -98dBm (Input terminated and 0 dB RF attenuation, preamplifier off) | |
| RF Input VSWR (at Tuned Frequency) | 10MHz to 1.6GHz | ＜1.5:1, nominal Attenuator setting 10~20dB |
| Reference Iinput Frequency | 10MHz | |
| Reference Input Amplitude | 0~10dBm | |
| Trigger Voltage | 5V TTL level | |
| Connector and Output Impendence | N female；（50Ω） | |
| NO | Item | Specifications | PostEnvironmental Tolerance |
| 1 | Range of Receiving Frequency（MHz） | 1575.42±1.1 | ±2.5 |
| 2 | Center Frequency(MHz) | 1575.42 | ±3.0 |
| （with 30mmSpuareGND plane） | |||
| 3 | Band Width(MHz) | ≥10 | ±0.5 |
| (Retum Loss≤-10dB) | |||
| 4 | V.S.W.R(in Center Frequency) | ≤1.5 | ±0.5 |
| 5 | Gain (Zenith)(dBi typ) | 4.5 | ±0.5 |
| (with 70mmSquare GND plane) | |||
| 6 | Axial Ratio | 3.0dB | ±0.2 |
| (with 70mm Square GND plan) | |||
| 7 | Polarization | Right-Handed Circular | ---- |
| 8 | Impedance(Ω) | 50 | ---- |
| 9 | Frequency Temperature Coefficient(ppm/℃) | 0±10 | ---- |
| Type | Dimensions(DN) | Working Voltage | Flow Rate Range | Length | Male & Female | Length of Thread | Material |
| YF-B1 | DN15 | 5V~15V(DC) | 1~25L/min | 44mm | Double Male | 10mm | Copper |
| YF-B2 | DN15 | 5V~15V(DC) | 1~25L/min | 50mm | Male in Female out | 10mm | Copper |
| YF-B3 | DN15 | 5V~15V(DC) | 1~25L/min | 66mm | Double Male | 18mm | Copper |
| YF-B4 | DN15 | 5V~15V(DC) | 1~25L/min | 66mm | Male in Female out | 10mm | Copper |
| YF-B5 | DN20 | 5V~15V(DC) | 1~30L/min | 50mm | Double Male | 10mm | Copper |
| YF-B6 | DN20 | 5V~15V(DC) | 1~30L/min | 60mm | Double Male | 11mm | Copper |
| YF-B7 | DN15 | 5V~15V(DC) | 1~25L/min | 66mm | Double Male | 10mm | Copper |
