• MOQ 01 Piece
• TypeSock Knitting Machine

features :- all materials of needles system is adopted the technology of japan, and have a good stability, wearable. drumless, fully computer control electro-pneumatic yarn finger and cam control. stepping motor for elastic yarn and stitch cam control the double picks, the double lift needle to beat a heel, can knit y heel automatic stop by a sensor when every error occurs one main feeder + 5 pattern feeders (1+14 colour) equipped the ups machine can keep the memory of program and the knitting action if transient electric power cut happened, when the power restored, machine can continue the knitting knitting can be operated through keyboard and lcd the fog form of needle tube is even to provide oil, reducing fabric greasy dirt. .

The compact design of Krish EC-8 has been developed as the new generation of Single Cylinder Hosiery Machine for the 21st Century. This generation of machine has new shape and more color combinations, more patterns and more socks designs which led to the increased productivity with higher machine proficiency. Features :- Dual concept of making Terry Sports and Dress Socks. Japanese WAC High Speed Actuators for advance selections. Dual Dropper and Picker System to produce high quality and increase productivity during formation of Heel and Toe, than traditional which is single cam and pickers system. Pneumatic system to control yarn fingers. Machine Stops automatically through Sensors which prevents Yarn and Needle Breakage. Centralized Oil Lubrication system is controlled by Pneumatic device which ensure smooth working of Mechanical components of the machine. Ring Cutter stops during Heel and Toe to maintain long life of the shape edges and accurate trimming. Elastic yarn feeding is controlled by Steeping Motor for maintaining uniform size. Stitch Quality control by Stepping Motor for size control through course length and width. Auto Testing, Error sensors and self protection system, Drum less fully electronic computerized socks knitting machine driven by Brush less Servo Motor. Equipped with UPS to maintain the memory of programs and Knitting action in case of Electric Power failure. On Restoring, the Machine continue to knit again from the same portion. This saves from yarn and socks wastage. USB for downloading & uploading data of socks Patterns / Designs directly to the Machine.

• Model / DescriptionZDCI - 1F
•
• Cylinder Diameter4"
• Needle Range120 ~ 176N
• Running Speed280 ~ 300
• Servo Motor1.5 KW
• Control Box0.55 KW
• Net Weight380 KGS.
• Gross Weight430 KGS.
• Packing Diamension (W x L x H)1900 X 1020 X 920 mm

Double Cylinder Socks Knitting Machine can weave all kinds of socks such as men’s socks, women’s socks and children’s socks, even can knitting ribbed pattern. It is Fully Computerized  Controlled. The working speed is stable, brings efficiency and good quality. Features :- Fully Electronic Control weaving system, non-roller. Driven by Servo Motor, stepless speed regulating. Adjust yarn tension and weaving density by stepping motor. Sensing device is able to auto-protect, minimize the damage when there is breakdown. Kepping high speed running to improve the inner cam. Lines leading shuttle and cam switch are electro pneumatic controlled. Auto oil feeder system. Complete alarm system when needle break, line break needle tip break, electronic breakdown etc. Yarn changing unit, 6 colours are available. Y – Shape heel is available. Equipped with the UPS system can memory the current program and knitting action if transience power off. When the power restored, it can continue knitting to avoid any loss or wastage. Password – protection for parameter setup, to avoid the inadvertent change or unallowed modification, improve the reliability and safety. Available in 220V/380V/415V and 50/60 Hz.

• Voltage380 / 3Phase
• Diameter3½â��

machine run through the drive, which is used to control speed at various points. Folding attachment dw model provides seamless welt socks exactly like socks made on fully computerized machine. Elastic yarn feeding is controlled by disc for maintaining uniform size. Pattern design drum of 60 steps provides various combinations of design and scope. Three colors stripping plus one main feed color. Elastic can also be knitted in the foot portion of the socks. Machine stops automatically through sensors which prevents yarn & needles breakage. Movable stitch cam is used for size control of course length & width. Special design ring cutter is used for uniform cutting of yarn pattern. Suction device for automatic ejection of socks from the machine. Trimmed yarn gets collected in the waste container.

• MOQ 01 Piece
• TypeSock Knitting Machine

features :- all materials of needles system is adopted the technology of japan, and have a good stability, wearable. drumless, fully computer control electro-pneumatic yarn finger and cam control. stepping motor for elastic yarn and stitch cam control the double picks, the double lift needle to beat a heel, can knit y heel automatic stop by a sensor when every error occurs one main feeder + 5 pattern feeders (1+14 colour) equipped the ups machine can keep the memory of program and the knitting action if transient electric power cut happened, when the power restored, machine can continue the knitting knitting can be operated through keyboard and lcd the fog form of needle tube is even to provide oil, reducing fabric greasy dirt. .

The compact design of Krish EC-8 has been developed as the new generation of Single Cylinder Hosiery Machine for the 21st Century. This generation of machine has new shape and more color combinations, more patterns and more socks designs which led to the increased productivity with higher machine proficiency. Features :- Dual concept of making Terry Sports and Dress Socks. Japanese WAC High Speed Actuators for advance selections. Dual Dropper and Picker System to produce high quality and increase productivity during formation of Heel and Toe, than traditional which is single cam and pickers system. Pneumatic system to control yarn fingers. Machine Stops automatically through Sensors which prevents Yarn and Needle Breakage. Centralized Oil Lubrication system is controlled by Pneumatic device which ensure smooth working of Mechanical components of the machine. Ring Cutter stops during Heel and Toe to maintain long life of the shape edges and accurate trimming. Elastic yarn feeding is controlled by Steeping Motor for maintaining uniform size. Stitch Quality control by Stepping Motor for size control through course length and width. Auto Testing, Error sensors and self protection system, Drum less fully electronic computerized socks knitting machine driven by Brush less Servo Motor. Equipped with UPS to maintain the memory of programs and Knitting action in case of Electric Power failure. On Restoring, the Machine continue to knit again from the same portion. This saves from yarn and socks wastage. USB for downloading & uploading data of socks Patterns / Designs directly to the Machine.

• Model / DescriptionZDCI - 1F
•
• Cylinder Diameter4"
• Needle Range120 ~ 176N
• Running Speed280 ~ 300
• Servo Motor1.5 KW
• Control Box0.55 KW
• Net Weight380 KGS.
• Gross Weight430 KGS.
• Packing Diamension (W x L x H)1900 X 1020 X 920 mm

Double Cylinder Socks Knitting Machine can weave all kinds of socks such as men’s socks, women’s socks and children’s socks, even can knitting ribbed pattern. It is Fully Computerized  Controlled. The working speed is stable, brings efficiency and good quality. Features :- Fully Electronic Control weaving system, non-roller. Driven by Servo Motor, stepless speed regulating. Adjust yarn tension and weaving density by stepping motor. Sensing device is able to auto-protect, minimize the damage when there is breakdown. Kepping high speed running to improve the inner cam. Lines leading shuttle and cam switch are electro pneumatic controlled. Auto oil feeder system. Complete alarm system when needle break, line break needle tip break, electronic breakdown etc. Yarn changing unit, 6 colours are available. Y – Shape heel is available. Equipped with the UPS system can memory the current program and knitting action if transience power off. When the power restored, it can continue knitting to avoid any loss or wastage. Password – protection for parameter setup, to avoid the inadvertent change or unallowed modification, improve the reliability and safety. Available in 220V/380V/415V and 50/60 Hz.

• Voltage380 / 3Phase
• Diameter3½â��

machine run through the drive, which is used to control speed at various points. Folding attachment dw model provides seamless welt socks exactly like socks made on fully computerized machine. Elastic yarn feeding is controlled by disc for maintaining uniform size. Pattern design drum of 60 steps provides various combinations of design and scope. Three colors stripping plus one main feed color. Elastic can also be knitted in the foot portion of the socks. Machine stops automatically through sensors which prevents yarn & needles breakage. Movable stitch cam is used for size control of course length & width. Special design ring cutter is used for uniform cutting of yarn pattern. Suction device for automatic ejection of socks from the machine. Trimmed yarn gets collected in the waste container.
