Synergy Telecom Pvt. Ltd.

Synergy is Indian Antenna and RF Co-axial Cable assembly manufacturer. We deal in rf connector, rf Co-axial Cable, all types of antenna, antenna cables, jumper cables, microwave components, Attenuator, dummy loads, dc block, splitter, Duplexer, Couplers, Combiners, low pim test cables, tools, Ibs n DAS product, GPRS, rfid product's, Iot products, and 5g products for smart city, pls confirm if any enquiry across.

Center Conductor Bare Copper wire 2.69 Insulation Solid PE 9.40 Shield Double Copper wire barding 90%+90% Jacket PVC 13.84

Cutoff Frequency 3 GHz Characteristics Impedance 50±2.5 Capacitance 95.50pF/m Min. Bending Radius mm Nominal Weight Kg/100m Temp Range -55° to +200°C

Center Conductor Solid Bare Copper 0.0370 inch 0.94 mm Dielectric Foamed Polyethylene 0.110 inch 2.79 mm Inner Shield Sealed APA Tape 0.116 inch 2.95 mm Outer Shield 36AWG, 95% Tinned Copper Braid 0.138 inch 3.50 mm Jacket Black PE 0.195 inch 4.95 mm

Center Conductor Solid Bare Copper 0.0441 inch 1.12 mm Dielectric Foamed Polyethylene 0.116 inch 2.95 mm Inner Shield Sealed APA Tape 0.123 inch 3.12 mm Outer Shield 36AWG, 90% Tinned Copper Braid 0.144 inch 3.65 mm Jacket Black PE 0.195 inch 4.95 mm

Center Conductor Solid Bare Copper 0.0559 inch 1.42 mm Dielectric Foamed Polyethylene 0.150 inch 3.81 mm Inner Shield Sealed APA Tape 0.157 inch 3.99 mm Outer Shield 36AWG, 95% Tinned Copper Braid 0.178 inch 4.51 mm Jacket Black PE 0.240 inch 6.10 mm

Center Conductor Solid Copper Clad Aluminum Wire 0.0701 inch 1.78 mm Dielectric Foamed Polyethylene 0.190 inch 4.83 mm Inner Shield Sealed APA Tape 0.196 inch 4.98 mm Outer Shield 112/0.15 AL-MG(90-94%) 0.225 inch 5.72 mm Jacket Black PE 0.300 inch 7.62 mm

Center Conductor Solid Copper Clad Aluminum Wire 0.0701 inch 1.78 mm Dielectric Foamed Polyethylene 0.190 inch 4.83 mm Inner Shield Sealed APA Tape 0.196 inch 4.98 mm Outer Shield 112/0.15 AL-MG(90-94%) 0.225 inch 5.72 mm Jacket Black PE 0.300 inch 7.62 mm

Center Conductor Solid Bare Copper 0.0441 inch 1.12 mm Dielectric Foamed Polyethylene 0.116 inch 2.95 mm Inner Shield Sealed APA Tape 0.123 inch 3.12 mm Outer Shield 36AWG, 90% Tinned Copper Braid 0.144 inch 3.65 mm Jacket Black PE 0.195 inch 4.95 mm

Center Conductor Solid Copper Clad Aluminum Wire 0.1091 inch 2.77 mm Dielectric Foamed Polyethylene 0.285 inch 7.24 mm Inner Shield Sealed APA Tape 0.292 inch 7.42 mm Outer Shield 34AWG, 90% aluminium Braid Braid 0.320 inch 8.12 mm Jacket Black PE 0.405 inch 10.29 mm

Center Conductor Solid Copper Clad Aluminum Wire 0.1760 inch 4.47 mm Dielectric Foamed Polyethylene 0.455 inch 11.56 mm Inner Shield Sealed APA Tape 0.463 inch 11.76 mm Outer Shield 34AWG, 90% Tinned Copper Braid 0.491 inch 12.47 mm Jacket Black PE 0.590 inch 14.99 mm

Items MaterialItems Diameter(mm) Center conductor silver plated copper cover 0.94 Dielectric Solid PTFE 2.95 1 out shield silver plated copper wire braiding 3.60 2 out shield silver plated copper wire braiding 4.191 Jacket FEP (BROWN) 4.95 __________________________________________________________________________

Center Conductor Silver Plated Copper cover steel wire 7/ 0.102 Insulation Solid PTFE 1.6 Shield Tin Plated Copper Wire Braiding 16/5/0.1(18-19) Tin Immersion 3.52 Jacket FEP(Brown) 2.54

Center Conductor Silver Coverd Copper 7/0.18 Insulation PTFE 1.52 Wire Braide Silver Coverd Copper 80*0.10 Jacket FEP 2.54

Center Conductor Bare Copper wire 7/ 0.15±0.008 Insulation Solid PE 1.50±0.05 Shield Bare Copper Wire Braiding 16*4/0.08(87%) Jacket PVC(Black) 2.8±0.15

Center Conductor Bare Copper 0.0900 inch 2.29 mm Dielectric Foamed Polyethylene 0.285 inch 7.24 mm Outer Shield Copper Braid 0.314 inch 7.98 mm Jacket Black PVC 0.405 inch 10.29 mm

Center Conductor Bare Copper wire 7/0.752 Insulation Solid PE 7.24 Shield Double Copper wire barding 93%+90% Jacket PVC 10.8

Center Conductor Copper Clad Steel 0.0177 inch 0.45 mm Dielectric Solid Polyethylene 0.061 inch 1.54 mm Inner Shield Unsealed APA Tape 0.065 inch 1.65 mm Outer Shield 38AWG, 90% Tinned Copper Braid 0.081 inch 2.05 mm Jacket Black PE 0.110 inch 2.79 mm

Center Conductor Silver Plated Copper cover steel wire 7/ 0.102 Insulation Solid PTFE 1.6 Shield Tin Plated Copper Wire Braiding 16/5/0.1(18-19) Tin Immersion 3.52 Jacket FEP(Brown) 2.54

Meterial Tinned Copper

Diameter of Each Strands MM 0.71 0.015 MM

Nominal Cross Section Area Sqmm 0.395

Meterial Polythelin

Insulation Thickness MM 1.00 0.05

Core Diameter MM 2.85 0.2
