Aquatech Pumping Solutions

Chakrata Road, Dehradun, Uttarakhand

Pump Efficiences up to 83% which provide faster and more efficient pumping resulting in savings to the end user.

• Low fuel usage
• Reduced engine sizes
• Lower maintenance costs
• Dry self prime and reprime
• Close coupled SAE Bearing Frames
• Operates in ‘snore’ conditions
• Vacuum Priming option available for ground dewatering.
• Diesel, electric or hydraulic drive

Pump Efficiences up to 83% which provide faster and more efficient pumping resulting in savings to the end user.

• Low fuel usage
• Reduced engine sizes
• Lower maintenance costs
• Dry self prime and reprime
• Close coupled SAE Bearing Frames
• Operates in ‘snore’ conditions
• Vacuum Priming option available for ground dewatering.
• Diesel, electric or hydraulic drive

The FBP400 has been designed for applications requiring extremely high flow rates with medium heads. It is driven by a Caterpillar C-27 engine via a gearbox so the pump operating speed is very low. It’s dual compressor priming system greatly reduces priming times required for larger pipes and long suction lengths. The pumps ability to handle large solids up to 7”/ 178mm makes it ideal for use in municipal, mining and construction industries.

Innovations include the introduction of a flooded, oil-lubricated pump bearing set-up and leak-free pump bearing isolator in place of the grease lubrication system featured in many other pumps. This neatly sidesteps the usual threat of pump failure due to either too much or too little grease - or because of contamination.

• Closed coupled pump SAE # 1 - virtually eliminates pump / engine misalignment
• Flooded oil lubricated pump bearing set up
• Pump Bearing Isolator set up
• Excellent suction lift capabilities at high flow at variable diesel speeds (1, 300 - 1, 600rpm)
• Pump efficiency (77%)

Pump Efficiences up to 83% which provide faster and more efficient pumping resulting in savings to the end user.

• Dry self-prime and reprime
• Operates in “snore conditions
• Diesel, electric or hydraulic drive
• Suction lifts up to 9m
• Solids handling to 90mm
• Low fuel usage
• Replaceable wear plates

Pump Efficiences up to 83% which provide faster and more efficient pumping resulting in savings to the end user.

• Low fuel usage
• Reduced engine sizes
• Lower maintenance costs
• Dry self prime and reprime
• Close coupled SAE Bearing Frames
• Operates in ‘snore’ conditions
• Vacuum Priming option available for ground dewatering.
• Diesel, electric or hydraulic drive

Pump Efficiencies up to 83% which provide faster and more efficient pumping resulting in savings to the end user.

• Low fuel usage
• Reduced engine sizes
• Lower maintenance costs
• Dry self prime and reprime
• Close coupled SAE Bearing Frames
• Operates in ‘snore’ conditions
• Vacuum Priming option available for ground dewatering.
• Diesel, electric or hydraulic drive

Pump Efficiencies up to 83% which provide faster and more efficient pumping resulting in savings to the end user.

• Dry self-prime and reprime
• Operates in “snore conditions
• Diesel, electric or hydraulic drive
• Suction lifts up to 9m
• Solids handling to 90mm
• Low fuel usage
• Replaceable wear plates

Pump Efficiences up to 83% which provide faster and more efficient pumping resulting in savings to the end user.

• Low fuel usage
• Reduced engine sizes
• Lower maintenance costs
• Dry self prime and reprime
• Close coupled SAE Bearing Frames
• Operates in ‘snore’ conditions
• Vacuum Priming option available for ground dewatering.
• Diesel, electric or hydraulic drive
