Actuators are a device for moving hvac door flap to control temperature, fan speed, and air circulation inside of vehicle. Newbase actuator are widely used as the servo motor of water valve , fresh air device and air blowing grid in the vehicle air conditioning & heating system. It’s also used for engine cooling system to control the openclose of cooling water box.

Company Frame: Vehicle controlling products Dept: Guangzhou parent company-Zhengzhou company-Canada company Industrial controller and software Dept: Guangzhou parent company-Zhengzhou company-Jiangxi company-Fuzhou company Commision: Customonized for bus AC&RV AC manufacturing enterprise and OEM supply Fast delivery and powerful production capacity: We have many years experience in OEM & ODM and have obtained great production capacity. All that can ensure fast delivery. For big customers, virtual inventory at customers’ side will be established to ensure stable and long term demand. Superb technology advantages: We have been in the climate control field for nearly 2 decades, the R&D and product philosophy are leading the trade and many have got patents in China. Our professional engineers, who are familiar with customer’s demand, would recommend customers a variety of suitable products specifically. According to customer’s requirements, the engineers choose the suitable mode and design for customers. Meanwhile, their adequate experience can also help when you have problems in application. Strict quality control system and good after sale service: We have got QS9000, CE and UL certifications for our products and carry out strict quality control in production. Our branches and distribution nets are widespread and our professional engineers and sale staff will offer superb technical support and after sale service. You will be released from fear of any trouble!

XF-1 FRESH AIR DAMPER 1.Function: XF-1 fresh air device applies to control the ventilation door of the fresh air device in the bus AC system. Material: ABS, aluminum-plastic fan, 3M filter, preplaced nut, seal and reliable, turn smoothly and easy assemble. Turn onoff the fresh air device of AC system by putting throughcutting off the control wire. 2.Application case: YUTONG BUS, HENGTONG BUS 3.Accessories: 1. Assemble hole: plentiful selects, or customization 2. Connector: customization. 4.Wiring Diagram: Technical data: Code XF-1 Power supply DC24VDC12V Power consumption 3W Current Max.70mA Electrical connection Max.1m X 0.5mm² Direction of rotation CWCCW Area of the damper 0.042m² Torque 4kgf.cm Running time 3.5±0.5rpm Locked current Max.250mA Noise level Max.43dB(A) Ambient temperature -30°c—80°c Storage temperature -40°c—85°c Life Max.200, 000 cycle Dimensions 545x135x70(mm) Weight 970g Quality certification TS16949ISO9001 Advantages: a. Mature&stable b. Wiring customized c. Competitive price d. Make comfortable temperature&humidity

Description CG220209 digital air conditioner controller applies to internal climate control for construction vehicle, truck, van, etc Main function Cooling YES Heating YES Ventilation NO Fresh Air NO Power lost memory YES Error alarm YES Auto over-voltage protection YES Air flow regulation 3 grades Interior temp display YES The shift function (check by manual operation) -Compel cooling -Check defrost temp Application: FOTON, CANCOO Technical Data Power supply DC12V24V Power consumption 2 W Current Max.200mA Dimensions 132X62X54mm Input 1) Interior temp. sensor 2) Defrost sensor 3) Pressure sensor 4) AC power(generator) 5) ACC(battery) 6) Backlight power Output 1) Fan high 2) Fan medium 3) Fan low 4) Compressor clutch 5) Heating Display LED Ambient temperature -30℃—80℃ 5%－95%RH Non-condensing Storage temperature -10℃—70℃ 5%－95%RH Non-condensing Display precision Temp value. Dual digit display, Accuracy, 1 °c Protection IP43 EMC EN50081&EN50082-2 Security level Applied to EN61010-II, Pollution degree: II Weight 170g Dimension drawing Advantage a. Full function: Heating, cooling, fan speed control, Air flow angle control, Fresh air ventilation b. Standard product, fast delivery c. Mature technology, stable design d. Program customer design e. Custom LOGO

CJ210202 Auto air conditiog controller Description CJ210202 air conditioner controller applies to the internal climate independent control of bus, car, mini bus, Van, etc Main function Cooling YES Heating YES Ventilation NO Fresh Air YES Auto control YES Power lost memory YES Error alarm YES Auto over-voltage protection YES Air flow regulation PWM Air blowing setting YES Interior temp display YES Technical Data Power supply DC12V24V Power consumption 5W Current Max.300mA Dimensions 180X75X95mm Input 1) Interior temp. sensor 2) Defrost sensor 3) Pressure sensor 4) ACC(battery) 5) Backlight power 6)AC power 7)Rear warming ari high speed signal 8)Rear warming air low speed signal Output 1) Cooling 2) Rear warming air fan high 3) Rear warming air fan low 4)Fresh air 1 5)Fresh air 2 6)Defrost 7)Head blowing 8)Feet blowing 9)Head&feet blowing 10)Defrosting&feed blowing Display LED Ambient temperature -30℃—80℃ 5%－95%RH Non-condensing Storage temperature -10℃—70℃ 5%－95%RH Non-condensing Display precision Temp value. Dual digit display, Accuracy, 1 °c Protection IP43 EMC EN50081&EN50082-2 Security level Applied to EN61010-II, Pollution degree: II Weight 340g Dimension drawing Advantage 1. Apply to the HVAC control of bus, mini bus, car, Van, etc 2. Customer-oriental design is available 3. Mature product for volume production 4. Semi-auto design

Water valve NENEWASE water valve is combined by NEWBASE actuator and the valve body. 1.Function: Adjust the water flow through switching the polarity of actuator. 2.Types According to the actual application, 2-wire, 3-wire or 5-wire actuator is optional. ONOFF Type — two wires, it open the valve to some an angle and close by changing the polarity of wiring. Switch ONOFF Type — three wires, it turn onoff the valve by putting throughcutting off the control wire. Temp Type — five wires, the actuator operates by switching the polarity of wiring, it could also give a feedback of the opening to the HVAC system. Mode Type — seven wires, it could control the valve to stop on different opening percentage. Voltage control Type — it turn onoff the valve gradually , driven by 0~10 V voltage signal Manual Type — the valve is onoff by hand with a force arm. 3.Application : NEWBASE water valve is widely used for Vehicular Air Conditioning & Heating Control System, such as bus, van, auto , engineering truck, refrigeration system and so on. 4.Accessories: 1. Bracket: plentiful selects, or customization; 2. Lever: plentiful selects, or customization; 3. Connector: customization.

Description CK200216 air conditioner controller applies to the climate control of bus, truck, agriculture machinery, etc. Main function Cooling YES Heating YES Fresh Air YES Voltage indicator NO Auto Control YES Power lost memory YES Error alarm YES Auto over-voltage protection YES Air flow regulation 3 grades Interior temp display YES Exterior temp display NO The shift function (check by manual operation) -Defrost temp display -Compel cooling Technical Data Power supply DC24V12V Power consumption 2.5w Current Max.200mA Dimensions(mm) 118X54X22mm Input 1) Interior temp. sensor 2)Defrost sensor 3)Pressure switch 4)Voltage detection 5)ACC power Output 1)Compressor clutch 2)Fan high 3)Fan medium 4)Fan low Display LED Ambient temperature -30°c—80°c 5%-95%RH Non-condensing Storage temperature -10°c—70°c 5%-95%RH Non-condensing Display precision Temp value. Dual digit display, Accuracy, 1 °c Protection IP54 EMC EN50081&EN50082-2 Security level Applied to EN61010-II, Pollution degree :II Weight: 100g Dimension drawing Advantage 1. Smart design, full function 2. Program customer-design 3. Custom logo
