FFV Industrial Valves Manufacture Double Window/Single Window Sight Glass Valve, Full View Sight Glass.
Air Filters are primary filter to remove water, dust, and debris from air line. Range is measured in micron these are used in different industrial applications.
Air RegulatorRegulate and Reduces supply air pressure to a required working pressure.
Air LubricatorIt injects an aerosolized stream of oil into an air line to provide lubrication to the internal working parts of pneumatic systems used.
FFV Makes Round Body / Square Body Pneumatic CylinderPneumatic cylinders are devices for converting the air pressure into linear mechanical force and motion.Based on application and usage Air cylinders are classified, as light duty, medium duty or heavy duty types.Single acting cylinders have single air inlet line.Double acting cylinders have two air inlet lines.
FFV make Y Type Strainer Bolted Cover, Self Cleaning by opening the blow-off connection.Strainers are employed in pipelines to protect downstream mechanical equipment such as Condensers, heat exchangers, pumps, compressors, meters, spray nozzles, turbines and steam traps from the detrimental effect of sediment, rust, pipe scale or other extraneous debris.
On-off type or modulating type FFV make control valves are widely used for machinery, and plant engineering for steam controlling lines, thermic fluid lines, various liquid lines, heat exchanger, pumps pipes lines & gases.
A pipeline strainer is a device which provides a means of mechanically removing solids from A flowing fluid. This is accomplished by utilizing a perforated metal, mesh or wedge wire straining element. The most common range of strainer particle retention is 1 to 40 micron (0.0016).
Generally, compressed air is vulnerable to various types of contaminations that greatly reduce its value as a power source and can have a profound effect on the machinery that it operates. Moisture is the most common and the most hazardous contaminant present in the air.Moisture Separatos are used to Separate Moisture From Compressed Air Line Application and can be protect the expensive pneumatic instruments.
A rotary union is a union that allows for rotation of the united parts. It is thus a device that provides a seal between a stationary supply passage (such as pipe or tubing) and a rotating part (such as a drum, cylinder, or spindle) to permit the flow of a fluid into and/or out of the rotating part. Fluids typically used with rotary joints and rotating unions include various heat transfer media and fluid power media such as steam, water, thermal oil, hydraulic fluid and coolants.A rotary union is sometimes referred to as a rotating union, rotary valve, roto seal, rotary couplings, rotary joint, rotating joints, hydraulic coupling, pneumatic rotary union, through bore rotary union, air rotary union, vacuum rotary union.
A rotary union will lock onto an input valve while rotating to meet an outlet. During this time the liquid and/or gas will flow into the rotary union from its source and will be held within the device during its movement. This liquid and/or gas will leave the union when the valve openings meet during rotation and more liquid and/or gas will flow into the union again for the next rotation. Often functioning under high pressure and constant movement a rotary union is designed to rotate around an axis. A rotary unions design can be altered to change this or to increase the psi or rpm it needs to withstand as well as the number of valves required.
Rotary unions are also heavily used in Various Industries Like crude oil processing, the chemical industry, commercial food production, Paper, Plastics, Printings, Steel, pharmaceutical applications etc.
Quick release coupling is a coupling used to provide a fast, make-or-break connection of fluid transfer lines.Operated by hand, quick connect fittings replace threaded or flanged connections, which require wrenches. When equipped with self-sealing valves, quick connect fittings will upon disconnection, automatically contain any fluid in the line.
Quick Release Couplings are used in a wide variety of plumbing, heating, electrical and fire suppression systems.Quick Fitting is the original inventor of quick connect for electrical, fire suppression and plumbing technologies, Quick connect works by inserting the tubing into a connection mechanism that deploys fastening teeth onto the tubing surface. When opposing force is applied to the union, the teeth are forced deeper into the tubing, preventing separation of the union. Quick connect fittings offer a significant time saving benefit over traditional technologies and require little skill for their usage.
FFV Offer For Various types of High Quality Push in Fittings Like Male & female Straight Connector, Equal and Unequal Y, Tee, Elbow, Union Reducer, Union cross banjo elbow, branch tee, run tee, speed controller, Bulk head union, Plug in reducer, Stop fitting exhaust, Standard flat & Plastic silencer
DescriptionPush connect fittings are compact and single piece which are rated for certain temperature & pressure. The offer product ranges is made up of high quality basic material such as metal & alloys. These products offer superior performance and are available in a variegated range of shapes & sizes.
The tightness is made possible by the presence of material gripping and an o-ring inside the Push fitting. Once the tube is inserted to the bottom of the fitting, the steel collet inside grips the tube and prevents it from being released.
The tubing is disconnected by simply pushing the metal release inside and removing the tube from the push-to-connect fitting.Push-to-Connect fittings enable quick tubing connection and disconnection.Clients can also avail these fittings in customized forms as per their requirements.
