Features : Electro mechanical drive system for accuracy and high reliability, Digital Display for load and elongation, Simple push button controls for ease of operation
Maximum Crosshead Stroke : 1000 mm without load cell & grips.
Load Measuring Range and Accuracy : + 1% on indicated load from 2 % to 100 % of load capacity.
Drive System Option - SD with servo drive : 0.5 mm to 500 mm/min {Any other speed range available on request)
Distance between Columns : 450 mm
Supply Type : Manufacturer
Country of Origin : India
Measuring System Microcontroller Panel Crosshead Display Resolution Load Range & Resolution : Model Di-mp 0.1 Mm By Means of Rotary Encoder 1 /10000 from 0-40 %of Range and 1 / 4000 from 40-100%
Drive System Option - DD with DC drive : 1:10speed ratio 5 - 50 mm / min, 25 - 250 mn/min, 50 - 500 mm/ min (Any other speed range available
Power Supply : 230 V AC/50Hz, 1 Ph 415 V AC/50Hz, 3 Ph
