| Packing Dimension | 3200*1950*1700 |
|---|---|
| Table Structure | Cast Steel |
| Spindle Speed. | 0 -15000RPM |
| Guide Rail | Lm Guide Rail 20 / mm Hiwin |
| Electronic | Schneider & Siemens |
| Voltage | 220V |
| Oil Pump | Manual Oil System |
| Table Size | 1425*3000*250 mm |
| Transmission X/Y | X/Y Helical Rack&pinion (Bai Qiang) |
| Spindle Power. | 3.2 KW / Water Cooled Spindle |
| Moving System | Belt System / Helical |
| Main Switch | Omron |
| Machine Accuracy | <0.3 mm |
| Dust Collector | Optional 3KW |
| Body Weight | 1050 Kg |
| Motor & Driver | Stepper Mo Tepper Motor Yako Drive |
| Controller | Nc Studio |
| Collet | 3mm/6mm/12mm and Spiner |
| Working Size | X-1300* Y-2500*Z-250MM |
| Tool Box | 2 Pieces 20 Type Bits |
| Transmission ZZ | 25mm Z Ball Screw Drive With Break System -tbi -taiwan |
| Bed Structure | T Slot Aluminium Table |
| Max Air Move Speed | 20000mm/min |
| Max Working Speed | 10000mm/min |
| Inverter | Rituo & Best Vdf |
