APS Horizontal Autoclave

We offer Horizontal Autoclave-(Triple walled with Steam Jacket).
The autoclave is mounted on a Mild Steel tabular stand. The autoclave Chamber & steam jacket are made of 14 SWG. Stainless steel, Outer shell which serves as a cover is made of stainless Steel. Steam jacket allows dry sterilization. Hinged door is made of stainless steel. Radial Locking arms prevent opening of the door while Steam is inside the chamber. Autoclave is fitted with neoprene gasket; steam is generated in a separate boiler which is placed below the main body. Multiport valve is provided for Steam, dry sterilization & steam exhaust.
Autoclave is fitted with easily replaceable heaters and water level indicator. Autoclave holds pressure at selected point between 10 to 20psi +- 3 psi. Pressure control has markings which are approximate; the actual pressure is as shown by the pressure gauge. Hydraulically tested at 40psi. Fitted with safety valves pressure is as shown by the pressure gauge. Hydraulically tested at 40psi. Fitted with safety Valves pressure gauges, steam release valve, steam trap, and one tray
Available in following capacities
Size Litter Capacity Load
350mmX550mm 52 Litters 6 Kw
400mmX600mm 75 Litters 9 kw
400mmX1100mm 138 Litters 12 kw
450mmX600mm 95 Litters 9 kw
500mmX1200mm 235 Litters 12 kw
600mmX1200mm 340 Litters 15 kw
