Cast Iron AWWA C515 Gate Valve, Power : Manual

AWWA C515 Gate Valve
Our range:butterfly valve,gate valve,check valve,globe valve,ball valve,y strainer,rubber joint

awwa c515 resilient seat gate valve
specifications
1.suitable media: water.
2.face-to-face conform to ansiasme b16.10.
3.nominal diameter: dn40~dn600 (1 12"~24").
4.tightness check: awwa c509c515 api 598iso 5208en12226-1.
5.operator: cap top, hand wheel, gear box, electric actuator, etc.
6.flange: ansiasme b16.1 ansi b16.5 class 125, ansiawwa c11021.10.
7.working temperature:-20 to 120 centigrade . (epdm:-20 to 120, nbr: -10 to 80).
8.working pressure: class125, class150, 250 psi (2"~12"), 200 psi (14"~24"), 150 psi.

Main parts materials
a)seat: epdmnbrbrass.
B)gland follower: brassductile iron.
C)bolt and nut: stainless steel, steel with zinc.
D)stem: stainless steel, brass, bronze, steel with zinc.
E)hand-wheel: ductile iron malleable ironcarbon steel.
F)bodybonnetdisc: cast ironductile ironcidigg25ggg40ggg50ht200qt450.

Delivery & packaging
delivery detail: general within 30 days or according to the order quantity.
Packaging detail: plywood case. (each pc into one bubble plastic bag, several pcs into one plywood case).
