RELAY TYPE:Â GP Relay
· 16A switching capability
· Standard PCB layout
· Dielectric strength between coil and contact 5KV
· Various of contact forms available
· Option for sealed and flux-tight type
· UL insulation gradeï¼ï¿½Class F
· Environmental friendly productÂ
Power Relays, High Power Relays, Power Relays Factory, China
Contact Ratings | |
Contact Form: | 1A, 1C; 2A, 2C |
Contact Material: | AgCdO, AgSnO2 |
Contact Load Capacity: | 1A,1C:16A/250VAC |
2A,2C:5A/250VAC | |
Max. Switching Current: | 16A |
Max. Switching Power: | 4000VA |
Mechanical Endurance: | 1*107OPS |
Electrical Endurance: | 1*105OPS |
· Outline dimension: 29 x 12.6 x 20.6mm
Â
Technical Ratings | |
Insulation Resistance: | 1000MΩ |
Dielectric Strength(Between coil&contact): | 5000VAC |
Operate Time (Max.): | 15ms |
Release Time (Max.): | 5ms |
Ambient Temperature: | -40â�� ~ 70â�� |
Terminal Type: | THT |
Â
Â
Â
Coil Ratings | |
Nominal Voltage | (5-48)VDC |
Nominal Coil Power | 0.54W,0.72W |
Â
