Fully Automatic Industrial Oil Processing Machine Manufacturer in Ludhiana Punjab India

Fully Automatic Industrial Oil Processing Machine Mild Steel

Name: Fully Automatic Industrial Oil Processing Machine
Brand: GOYUM
SKU: EI-6091099
Price: 6375000 INR
Availability: InStock
Rating: 4.5 (29 reviews)

Price:

63.75 Lakh -

72.25 Lakh / Piece Get Latest Price

Sold By : Goyum Screw Press

Send Inquiry

Product Specifications

BrandGOYUM
Driven TypeElectric
Machine TypeBoth Hot and Cold press
MaterialMild Steel
Crushing Capacity40 - 45 Ton in 24 Hours in Pre-Pressing, 30 - 35 Ton in 24 Hours in Single & Final Crushing
Installation TypeFloor Mounted
CertificationISO 9001:2008 Certified, CE Certified, ISO 14001 : 2015 Certified
Weight11,500 kgs
Packaging TypeWooden Box
ConditionNew
Voltage220V, 280V ,380V, 400V , 415V
Automation GradeSemi-Automatic,Semi Automatic
Phase TypeThree Phase
Operating TypeSemi Automatic
Usage/ApplicationIndustrial Use,Multi Seed Oil Extraction
TypeOil Press
FeaturesHigh Performance
Oil Extraction MethodBoth Hot & Cold
Seeds SupportedMulti-Seed
ModelGOYUM 600
Oil Yield EfficiencyHigh
Dimension (LxBxH)14’ x 5’6” x 16’6”
Expeller Motor3 Phase, 100 HP, 1440 RPM
Kettle Motor3 Phase, 20 HP, 1440 RPM
Warranty1 Year Against Manufacturing Defects
Country of OriginIndia
BrandGOYUM
Supply TypeManufacturer, Exporter, Supplier

Preferred Buyer From : All over the world

Product Overview

Fully Automatic Industrial Oil Processing Machine is used to extract oil from various types of edible as well as non-edible oil seeds & nuts.

Features:

Bodies and Base	Fabricated from Mild steel
Gearbox	Triple Reduction Gearbox with Helical Gears of Cast Steel and Pinions of Alloy Steel. Aligned with bodies on single fabricated base.
Chamber	Material: Cast Steel. Vertically fitted Feed End: - Size: Ø 9" x 36" Long, Discharge End: - Size: Ø 8" x 36" Long
Worm Assembly	Hard Face welded along with Discharge Ring and Sliding Ring
Main Worm Shaft	Can be withdrawn out without Disturbing the Gear Box. The Shaft is water cooled.
Crammer Shaft	For Extra Cramming of the Seed or Cake is fitted on the Feed Body and is driven by 2 H.P. Geared Motor.
Round Kettle (Cooker)	4 Stages with Steam Jackets of Ø 60” for efficient cooking of Seed. Pipe Fitting Contains Safety Valve, Steam Spray Pipe, Pressure Gauge, Steam Valves & Steam Traps. Exhaust Fan is also provided to extract excess steam or moisture from cooking chambers.
Cake Thickness	Can be Adjusted on Running Machine.
Oil & Oil Cake	Superior Quality
Maintenance	Minimum
Crushing Capacity	Differs with the density of oilseeds & nuts and quantity of oil in it.

Technical Specification

Model	Capacity	Motor Power	Length	Breadth	Height
GOYUM 600	50 – 60 TPD* in Pre-pressing 30 – 35 TPD* in Single & Final Crushing	3 Phase 100 HP for Expeller	12 ft	7 ft	7 ft
Cooker/Kettle		3 Phase 20 HP for Kettle	7 ft	7 ft	12.6 ft

Additional Information

Payment Terms L/CT/T
Port of DispatchMumbai / Mundra
Packaging DetailsWrapped in polythene sheet & then Packed in Quality Wooden Box (For Export)
Delivery Time15 – 20 days, but confirmed delivery time will be provided at the time of confirmation.
