High Speed, High-low Temperature Tensile Testing Machine

Introduction
l high speed and high-low temperature testing system is used to test and research with material, parts, component, constructural part, which made of metal, nonmetal, alloy, composite material, for high speed, high speed and high-low temperature environmental test.
L test for property of variety of textile, food, medcine, cosmetic, rubber, plastic, film, biology material.
L tensile, peeling, and welding strength test with electronic part.
L peeling, bending strength, fastening property test with printing circuit board.
L tensile test with wooden, paper, film production
l stress relaxation and adhesive strength test.
L high speed and high-low temperature tensile, compression, recycle tensile, tensile-tensile, tensile-compression test.
Important specification:
loading capacity
100n, 200n, 500n, 1000n, 2000n, 5kn, 10kn, 20kn, 50kn, 100kn
test speed
0.0001~600mmmin(240inmin)(100mms)
grade of speed
0.0001~6000mmmin (self-set in range)
starting time of tensile
0~6000mmmin1.0s
stopping time of tensile
6000mmmin~01.0s
precision of high speed
±0.2%
resolution of position for high speed
0.033μm
controlling precision of position for high speed
±0.2%
precision of loading
±0.5% of displaying value
gathering frequency
1000hz(self-setting point between 10hz and 1000hz)
high-low and high temperature environmental test chamber:
l range of controlling temperature for high temperature: rt+10℃~2200℃
l grade of high temperature : rt+10℃~100℃, ~300℃,~600℃, ~800℃, ~1000℃, ~1200℃, ~1600℃, ~1800℃, ~2200℃.
L range of controlling temperature for low temperature:-100℃~rt
l grade of low temperature: -10℃, -25℃,-40℃,-55℃, -65℃, -80℃, -85℃, -90℃.
L variety of structural type: opposite opening cyliner, square moving type, rotating rise and fall type, combining type.
