Machine Tensile Tester

The  tensile testing machine is based on the constant rate of traverse principle. During the test, the sample is hold between two jaws. The upper jaws is stationary, while the lower jaw is made to move at a designated fixed speed with the help of a motor.
The motor is fitted with a Gear box and a lead screw arrangement (25mm/min to 400mm/min). A sensor , connected with a load cell , senses the load exerted on the stationary jaw and directly indicates the reading in kgs. The tensile testing machine is fitted with special case hardened lead screws  for stability and durability. The machine is equipped with a standard branded motor and standard electrical wiring. The completely modular construction of the tensile testing machine ensures the trouble free maintainance and easy operation.
The frame of the tensile testing machine is fabricated using heavy mild steel in order to ensure that it has the requisite rigidity and strength. the machine incorporates various built in safety arrangements  such as over load and over travel protection.
The tensile testing machine is finished in autumn Gray & Blue combination painting. Further the bright chrome/ Zinc plating has been added to impart a corrosion resistance finish.
The instrument comes complete with instruction manual,& calibration certificate traceable to NABL approved Labs.
Features :

• Speed Control through variable Frequency drive
• Highly precise load sensor For Accurate result
• Maximum Grip to Grip travel length:900
• Heavy Duty & Rugged structure
• Over travel Protection
• Over load Protection
• Hardened lead screws for frictionless movement
• Machine will automatically move to home position after completion of test.
