magnetic separation machine

Magnetic separation machine

Listing ID #3826553

Get Latest Price
  • Supply Type Manufacturer, Exporter, Supplier
Preferred Buyer From : All over the world

Features   High intensity. High garden, high power rare earth magnets Available with flanges to suit square and round chutes Available with angle deflectors above and between the tubes for heavy....
View More Details
Send Enquiry
India International Company
Goregaon, Mumbai, Maharashtra
View Number
  • Member Since 10 Years
  • Nature of Business Retailer

Ask for more detail from the seller

Contact Supplier

Product Details no_img_icon

Features



  • High intensity. High garden, high power rare earth magnets
  • Available with flanges to suit square and round chutes
  • Available with angle deflectors above and between the tubes for heavy contamination
  • Direct access to magnets in chute
  • Easily installed and extremely easy to clean
  • Description



    Magnetic separation is generally a low cost method of recovery, unless high intensity separators are required. The electro-magnetic high intensity separators that produce 20,000 gauss; the rare earth magnetic separators are relatively inexpensive and can produce magnetic fields around 6,000 gauss. To different kinds of mineral ores, the application of magnetic separation machine is quite different.

  • Application



    Magnetic separator is mainly used in wet separating of the fine minerals with strong ferromagnetism. The wet-type drum permanent magnetic separator is mainly suitable for wet separating of the following ores with the sizes less than 3mm, which are magnetite, magnetic pyrite, baking ore, and limonite and so on.


Model Roller size Magnetic intensity on surface mT Processing ability Drive power Roller rotary speed Weight
(Dia.×Length)
mm Geometric center average highest T/h m3/h Kw Kg
CTS(N,B)-46 400×600   130 160 1~3 5 1.1 45 600
CTS(N,B)-66 600×600   145 170 5~10 16 1.1 40 750
CTS(N,B)-69 600×900   145 170 8~15 24 1.1 40 830
CTS(N,B)-612 600×1200   145 170 10~20 32 2.2 40 990
CTS(N,B)-618 600×1800   145 170 15~30 48 2.2 40 1330
CTS(N,B)-712 750×1200 120 155 180 15~30 48 3 35 1500
CTS(N,B)-718 750×1800 120 155 180 20~45 72 3 35 2100
CTS(N,B)-918 900×1800 148 165 190 25~55 90 4 28 2900
CTS(N,B)-924 900×2400 148 165 190 35~70 110 4 28 3500
CTS(N,B)-1018 1050×1800 148 165 190 40~75 120 5.5 22 4000
CTS(N,B)-1021 1050×2100 148 165 190 45~88 140 5.5 22 4500
CTS(N,B)-1021 1050×2100 160 240 280 45~88 140 5.5 22 4500
CTS(N,B)-1024 1050×2400 148 165 190 52~100 160 5.5 22 5000
CTS(N,B)-1024 1050×2400 160 240 280 52~100 160 5.5 22 5000
CTS(N,B)-1030 1050×3000 160 240 280 65~125 200 7.5 22 6200
CTS(N,B)-1218 1200×1800 148 165 190 47~90 140 5.5 19 5800
CTS(N,B)-1218 1200×1800 160 240 280 47~90 140 5.5 19 5800
CTS(N,B)-1224 1200×2400 148 165 190 82~120 192 7.5 19 6200
CTS(N,B)-1224 1200×2400 160 240 300 82~120 192 7.5 19 6200
CTS(N,B)-1230 1200×3000 148 165 190 80~150 240 7.5 19 7200
CTS(N,B)-1230 1200×3000 160 240 280 80~150 240 7.5 19 7200
CTS(N,B)-1530 1500×3000 180 240 300 90~170 270 11 14 8100
CTS(N,B)-1540 1500×4000 180 240 300 115~220 350 11 14 9300
