MULTIHIGH TEMPERATURE

STANDARD DUTY

Multihigh Temp composite hose is designed for handling hot viscous petroleum by products and where high temperature upto +180°C are requirement.

APPLICATION

The  assembly are recommended for handling hot viscous petroleum by products and where high temperature upto +180°C are requirement. The Spiral wound high tensile galvanized iron / Stainless Steel inner wire and outer wire for providing strength & the flexibility to maintain hose integrity under stress and strain.

COMPLIANCE

Multihigh Temperature composite hose are manufactured to suite High Temperature requirement.

PRODUCT HANDLE

Hot viscous petroleum by-product such as Tar and Bitumen.

FEATURES

1. Complete product compatibility for safe handling of all types Hot viscous petroleum by-products such as Tar and Bitumen.
2. Heat Resistant Fiberglass fabric outer cover.
3. Double end to end electrical continuity prevents static electricity build up and internal arcing.
4. Suitable for 0.9 Bar Vacuum rating.

CONSTRUCTIONS

• INNER WIRE : High tensile strength galvanized steel or Stainless Steel
• OUTER WIRE : High tensile strength galvanized steel or Stainless Steel
• CARCASS : Multiple layers of polyamide fabric, film
• COVER : Heat Resistant Fiberglass fabric
• TEMPERATURE RANGE : -30°C to +180°C (However pressure rating will reduce by 50% when temperature exceed 100°C)
• END FITTING : As per client requirement which will be externally crimped or swaged

SAFETY

•  assemblies are tested at 1.5 times rated W.P for safety & reliability in accordance with EN 13765.
• Manufacturer test certificate will be provided with the supply.
• Burst pressure Indicated is at ambient temperature.
• Electrically continuity is achieved by the two wire bonded to the end fitting, this helps dissipate accumulated charge and to avoid static flash.
