Contact SupplierTechnical Data:
Type ProfiTec 1200
Working area X/Y/Z 1000 x 1200 x 300 mm
Axis resolution 0,15 �µm (all axis)
Positional accuracy +/- 4�µm (VDI 3441)
Repeatability +/- 2�µm (VDI 3441)
Rigidity > 100 N/�µm
Weight approx. 4 t
Control system Andronic, BES, Eckelmann, Heidenhain
Drive digital AC-Servo-drive
Spindle power 1,2 - 14 kW
Spindle speed rpm up to 120.000 U/min
Tool changer system 5-tool positions
Description Optional: minimum spray cooling system, tool changer sytem with automatic tool length sensoring, dust removal and filtration system, 3D measuring sensor (infrared), 4. and 5. NC axis, machine guarding enclosure.
