Contact SupplierGrade | Variants | |||||
---|---|---|---|---|---|---|
Grade Name | Bp-09 | Bp-15 | Bp-04 | Bp-10FR | Bp-01 | Bp-25 |
Grade Name As Per IS 5831 | Type A | Type A | Type A | Type A FR | Type B | Type C |
Maximum Operating Temperature C | 70 | 70 | 70 | - | - | 85 |
Properties of PVC Compound Gravity | 1.30(+/-0.02) | 1.40(+/-0.02) | 1.45(+/-0.02) | 1.50(+/-0.02) | 1.35(+/-0.02) | 1.33(+/-0.02) |
Hardness Shore A | 88(+/-3) | 90(+/-3) | 90(+/-3) | 92(+/-3) | 94(+/-3) | 90(+/-3) |
Thermal Stability @ 200°C | 110 | 125 | 110 | 130 | 150 | 110 |
Volume Resistivity @ 27°C | 5 x 1013 | 1 x 1014 | 7 x 1013 | 7 x 1013 | 1 x 1014 | 1 x 1015 |
Tensile Strength N/mm2 | 16 | 17 | 16 | 15 | 18 | 18 |
Elogation At Break % | 250 | 250 | 250 | 230 | 180 | 200 |
Ageing Temperature °C | 80 | 80 | 80 | 80 | 100 | 135 |
Duration of Ageing, Hours | 168 | 168 | 168 | 168 | 168 | 168 |
Variation of Tensile Strength % (+/-) | 20 | 20 | 20 | 20 | 25 | 25 |
Variation of Elogation % (+/-) | 20 | 20 | 20 | 20 | 25 | 25 |
Loss of Mass mg/cm2 | 2 | 2 | 2 | 2 | 2 | 2 |
Oxygen Index (LOI) | - | - | - | 31 | - | - |
Temperature Index °C Min. | - | - | - | 300 |
