| Model | PRTL-12 | PRTL-16 | PRTL-20 | PRTL-24 |
|---|---|---|---|---|
| Length of Bed (With Head Stock) | 12" | 16" | 20" | 24" |
| Width of Bed | 26" | 26" | 28" | 28" |
| Height of center | 24" | 24" | 25" | 26" |
| Swing over Bed dia. | 47" | 47" | 51" | 51" |
| Swing in Gap dia. | 72" | 72" | 76" | 76" |
| Width of gap intent of face plate | 14" | 14" | 15" | 15" |
| Swing over saddle dia. | 37" | 37" | 41" | 41" |
| Admit between centre | 70" | 70" | 155" | 213" |
| Spindle hollow | 41/8" | 41/8" | 41/8" | 41/8" |
| No. of Spindle speed | 6 | 6 | 6 | 6 |
| Size of Morse taper | MT5 | MT5 | MT5 | MT5 |
| Lead screw pitch | 2PTI | 2PTI | 2PTI | 2PTI |
| Power required in H.P. | 7.5 | 10 | 15 | 20 |
| R.P.M. motor approx. | 960 | 960 | 960 | 960 |
| Approx. weight in Kgs. | 5000 | 6000 | 7200 | 8000 |
WE ALSO MANUFACTURER THE ABOVE MODELS WITH DIFFERENT BED WIDTHS AND CENTRE HEIGHT'S
